BACK-UP LAMPS
LIC
Customer Service: 800-562-5012 / Technical Support: 888-562-5012
99
3.340
3.380
1.375
80
®
Series Back-Up
Bulb Replaceable
Material:
• Acrylic lens
• Rubber housing
Light Source:
• Bulb: #1156, 32 cp
Replacement Parts:
• 99095C clear lens
FMVSS:
• R(2)
• Features rubber body which helps absorb
shock & vibration
• Can be used as back-up or utility lamp
• Requires two lamps to meet Federal Lighting
Regulations as a back-up lamp
• Not recommended for dome lamp use
80340
Clear lamp
0.16 screw hole diameter
1.12 mounting hole diameter
3.31
2.00
2.00
Surface Mount Back-Up
Bulb Replaceable
Material:
• Aluminum housing
• Polycarbonate lens
• Rubber grommet
• 16 gauge wire
Light Source:
• Bulb: #1156, 32 cp
Replacement Parts:
• 9076W clear lens
FMVSS:
• R(2)
• Heavy duty, economical &
efficient
• Allows one light instead of two
to comply with back-up lamp
regulations
• Polycarbonate twist-off lens &
O-ring seal
• Black plate housing: heavy gauge
anodized aluminum with staked
tubular bulb socket & waterproof
grommet on exit wire
92WD Clear lamp, retail pack
92WD
1.67"
6.50"
2.24"
1.67"
7.88"
3.31"
LED
66
®
Series
Back-Up
Sealed
1 Diode Pattern
Material:
• Polycarbonate lens, housing
& flange
Light Source:
• Light Emitting diodes (LEDs)
• Designed at 13.5v, 0.5 amp
Recommended Accessories:
• Mounting: Pages 262-263
• Plugs: Pages 216-217
FMVSS:
• R(2)
• Less current draw, resulting in increased battery & alternator life
while allowing more power for other vehicle requirements
• Single Diode technology
• Uses Fit ’N Forget® connection for increased corrosion resistance
• Two lamps required for back-up
• Must be mounted vertically
• Meets specifications for dome lamp applications
66205C Clear lamp
66206C Clear lamp & black flange
66404C Clear lamp & black flange, Hardwired
