DOME & UTILITY
LIC
Customer Service: 800-562-5012 / Technical Support: 888-562-5012
103
LED
Super 80
®
Dome
10 Diode Pattern
Material:
• Die cast aluminum housing
• White powder coat finish
• Polycarbonate lens
• Weight : <2 pounds
• Harness length : 6”, .180 bullet terminals
with 14 AWG SXL wire
Light Source:
• 10 Light Emitting Diodes (LED’s)
• Operating voltage : 7V-16V
• Current draw : 2A
• Power consumption : 22Watt@11v
1.08"
5.75"
18.19"
LED
Super 80
®
Dome
10 Diode Pattern
Material:
• Polycarbonate lens
• Die cast aluminum housing
• White powder coat finish
• 6” harness, blunt cut 14 AWG SXL wire
Light Source:
• 10 white Light Emitting Diodes (LEDs)
• Designed at 7v-16v, 2 amp, 950 lumens
• U.S. Patent #7244058
• Lower profile than competitive lamps, mounts in 1” deep pocket
• Nearly flush mount, .1” protrusion
• Not affected by cold temperatures
• LEDs provide whiter, brighter light
• Retrofit or replacement quick & easy
• Flicker free lighting in all temperatures
80251C Clear lamp
Recommended cutout
16.50 x 4.25
1.08"
5.75"
18.19"
Recommended cutout
16.50 x 4.25
• Robust LED Dome Lamp w/Motion Sensor located in center of lamp to power lamp on
• Movement is determined by changes in heat, stays on through 5 minutes of inactivity
• Recognizes movement up to 10’ away from lamp surface
• Nearly flush mount design, with only .1” protrusion to allow more room in vehicle body
• Not affected by cold temperatures, providing flicker-free lighting with a faster start-up time
• Ideal for refrigerated vehicles or those operating in cold weather
• LED’s provide whiter, brighter light rated at 1,000 lumens, providing clearer, improved visibility
• Solid-state LED design is impervious to damage from shock and vibration
• Retrofit or replacement is quick and easy, with a standard 16” x 4” cut-out necesarry for installation
• LED’s are fully encapsulated in epoxy to prevent damage caused by moisture and corrosives
80255C Clear lamp
