DOME & UTILITY
LIC
Customer Service: 800-562-5012 / Technical Support: 888-562-5012
104
LED
Dome
Model 707
4 Diode Pattern
Material:
• Polycarbonate lens
Light Source:
• Light Emitting Diodes
• Designed for 12 and 24
volt operation
• Current draw @ 12 volts:
1.25 amps
• Current draw @ 24 volts:
0.625 amps
• Ideal for flood, cargo, step, locker & overhead lighting
• Can be fitted in semi-trailer, trailer, box van, mini-bus/
coach, emergency services, utilities, recovery & load
handling vehicles
• Utilize an extremely reliable slimline design &
combines both dual voltage and dual polarity
functions
• Instant switch on with easy surface mount & offset
optical design making it easy to position in any
orientation to direct light to the desired area
• Low profile, waterproof to IP67 & reliable to a
temperature of minus 40 degrees C
• E approved LED interior lamp to EEC 95/54, EEC
2000/2, ECE Reg. 10
8013
Clear lamp
21.21
17.04
11.81
6.75
5.57
5.19
18.17
1.690
21.21
17.04
11.81
6.75
5.57
5.19
18.17
1.690
Fluorescent Interior
Flush Mount
Material:
• Steel housing
• Polycarbonate lens
• 1212915S Packard connection
Light Source:
• Two 15 watt F15T8 tubes
designed at 12v, 2.2 amps
Replacement Parts:
• 80700 ballast assembly
See page 103
• High impact snap-on polycarbonate lens
• Metal housing is white epoxy powder coated
• Installation is easy with integrated 2 pin
Packard connector
• Lamp plug connector mates with Packard
connector #12129081
80418 White lamp
0.24 screw hole diameter
18.250
5.500
1.625
• Designed for heavy use service vehicles
such as industrial supply trucks,
emergency vehicles or mobile kitchens
• Clear acrylic snap-lock lens
• Anodized aluminum housing features
black end caps
• Two 15 watt fluorescent tubes produce
light output of 1650 design lumens
• Convenient on/off switch
80444
White lamp
Fluorescent Interior
Surface Mount
Material:
• Anodized aluminum housing
• Acrylic lens
• Hardwired connectors, 18 ga.
Light Source:
• Two 15 watt F15T8/CW tubes
designed at 12v, 2.2 amp
