AIR BRAKE INVERSION VALVES
EUCLID NO.
NEW/REMAN REPLACES
CORE NO.
CORE GROUP
APPLICATION AND GENERAL INFORMATION
E-BN277340X
Reman
Bendix 277340X XC1085 BN358 Inversion Valves - An inverting, on/off, two way valve.
Normally the valve is open, and it is closed by air pres-
sure from another source. Used in parking brake and
sequencing applications. With 125 psi air pressure the
valve must begin to exhaust a 65 psi nominal ascending
control pressure. It must deliver full supply pressure with
40 psi nominal descending control pressure.
SPECIFICATIONS
CORE
GROUP
EUCLID NO.
NEW/REMAN REPLACES
A
B CORE NO.
APPLICATION & GENERAL INFORMATION
E-BN101450X
Reman
Bendix 101450X 25 psi 40 psi
XC1098 BN359
Inversion Valves - An inverting, on/off, two
way valve. Normally the valve is open, and it
is closed by air pressure from another source.
Used in parking brake and sequencing applica-
tions. With common control and supply pres-
sure inlet opens at "A" psi descending pressure
and the exhaust opens at "B" psi ascending
pressure.
E-BN280758X
Bendix 280758X 45 psi 60 psi
E-BN281318X
Bendix 281318X 35 psi 70 psi
E-BN288586X
Bendix 288586X 75 psi 90 psi
