174 / 206
U.S. 888-725-9355
XpresswayPlus.com
5-89
Canada 800-387-3889
TRANSMISSION VALVES
EUCLID NO.
NEW/REMAN REPLACES PORT SIZE
APPLICATION AND GENERAL INFORMATION
E-FUA5010N
Price Point Fuller A5010 1/16” (All)
Replaces the range valve on the 6, 7DL, 7L,8, 9, and 10 speed road ranger
transmission and range valve only on the 7DLL, 7LL, 8LL and 15 speed
Transmission. For use on transmission models: 610, 9509, 1110, 11610,
12610, 6610, 910, 11607L, 12509, 14608, 8609, 1157DL, 11608, 12510,
14609, 906, 11509, 11609, 12609, 14610, 9508.
E-FUA5010N will replace the range valve only on the transmission models:
958LL, 11608LL, 14608L, 915, 11615, 14615, 1157DL, 1258LL, 15615,
11607LL, 12515. To replace both the range and deep reduction valve see
E-FUA5015N.
EUCLID NO.
NEW/REMAN REPLACES PORT SIZE
APPLICATION AND GENERAL INFORMATION
E-FUA5015N
Price Point Fuller A5015 1/16” (All)
E-FUA5015N will replace both the range and deep reduction valve. But if
using to replace Fullers old style selector valve, it may require changing
the reduction cylinder cover and re-routing the reduction air lines. For use
on transmission models: 958LL, 11608LL, 14608LL, 915, 11615, 14615,
1157DLL, 1258LL, 15615, 11607LL, 12515.
EUCLID NO.
NEW/REMAN
REPLACES
POSITIONS
APPLICATION AND GENERAL INFORMATION
E-FUA4487N
Price Point
Fuller A4487
3 Position
E-FUA4490N
Fuller A4490
E-FUA4491N
Fuller A4491
