AIR BRAKE GOVERNORS AND LINE FILTERS
PRESSURE SETTINGS
EUCLID NO. NEW/
REMAN REPLACES CUT-IN CUT-OUT PORT SIZE CORE NO. COREGROUP APPLICATION & GENERAL INFORMATION
E-BN275491N New Bendix 275491
100 psi 120 psi
1/8” Ports
Standard Version. Pressure setting
range is adjustable. Governor - Signals
the unloading mechanism on the
compressor when to build up air to
the reservoir and when to halt air build
up. Usually between 100 and 120 psi.
Includes plugs for unused ports and
gasket.
E-BN275491X Reman Bendix 275491X
XC1077 BN251
E-BN275707X Reman Bendix 275707X
105 psi 125 psi
Low Temperature Version.
Weatherproof. Pressure setting range
is adjustable.
E-BN284358N New Bendix 284358 High Temperature Version. Pressure
setting range is adjustable. E-BN284358X Reman Bendix 284358X XC1077 BN251
PRESSURE SETTINGS
EUCLID NO. NEW/
REMAN REPLACES CUT-IN CUT-OUT PORT SIZE CORE NO. COREGROUP APPLICATION & GENERAL INFORMATION
E-MDKN18530X Reman MidlandKN18530X
100 psi 120 psi
1/8” Ports
XC1145 MD251
Governor - Signals the unloading
mechanism on the compressor when
to build up air to the reservoir and
when to halt air build up. Usually
between 100 and 120 psi.
E-MDKN18531X Reman MidlandKN18531X 1/4” Ports
Governor - Signals the unloading
mechanism on the compressor when
to build up air to the reservoir and
when to halt air build up. Usually
between 100 and 120 psi. Includes
plugs for unused ports and gasket.
E-MDKN18534X Reman MidlandKN18534X 105 +/-5 psi 115 psi 1/8” Ports
High Temperature applications.
Pressure setting range is adjustable.
