BRAKE HARDWARE
BRAKE REPAIR KITS
E-4515PHD STOPMATE UNIVERSAL KIT WITH “FREE-FLOATING” ANCHOR PIN FOR 16-1/2” BRAKES
ITEM QTY.
EUCLID NO.
DESCRIPTION
APPLICATION & GENERAL INFO.
1 2
E-1112A
Anchor Pin
For Eaton, Fruehauf, Meritor,
Spicer (Dana) and Std. Forge
brakes. Stopmate version of
E-1816SHD.
REPLACES:
Dayton/Batco 08100100
Dayton/Batco 08100160
Dayton/Batco 08100305
Dayton/Batco 08100360
Dayton/Batco 081035
Dayton/Batco 081717
Haldex 66735
Haldex CQ66735
Leland K109
Leland K116
Leland K45
Leland K75
Leland K9001
Meritor MKT4515PHD
Sirco TK4HD
Sirco TK4MPHD
2 4
E-1113
Washer
3 4
E-801
Lock Ring
4 2
E-2177
Roller
5 1
E-1880S
Return Spring
6 2
E-3007A
Roller Retainer
7 2
E-1893S
Anchor Pin Bushing
8 2
E-747
Spring Retainer
E-2821 MEGA PLUS EATON 18” SINGLE ANCHOR PIN BRAKE WITH CAST SHOES
ITEM QTY.
EUCLID NO.
DESCRIPTION
APPLICATION & GENERAL INFO.
1 2
E-2805
Retainer Spring
For use with the following Brake
Shoe: E-2801 (7”)
REPLACES:
Dayton/Batco 081096
Dayton/Batco 08109600
Eaton 1005006
Dana/Spicer 26A
Trailmobile 382821
Haldex CQ67406
Sirco EK2
Dana/Spicer HK26
Leland K275
Meritor R507072
2 1
E-2804
Return Spring
3 2
E-2802
Roller
4 2
E-2803
Roller Pin
E-3992 MEGA PLUS MERITOR 18” WITH NEW STYLE CAST SHOES
ITEM QTY.
EUCLID NO.
DESCRIPTION
APPLICATION & GENERAL INFO.
1 2
E-3511
Roller
For use with the following Brake
Shoe: E-4902 (7”)
REPLACES:
Dayton/Batco 081098
Dayton/Batco 08109800
Haldex CQ67408
Leland K281
Meritor KIT9408
Meritor R509408
Sirco RK2
2 1
E-543
Return Spring
3 2
E-502
Anchor Pin
4 4
E-1269
Anchor Pin Seal
5 4
E-801
Lock Ring
6 2
E-579A
Anchor Pin Lock Screw
7 2
E-919
Anchor Pin Bushing
8 4
E-2218
Brake Shoe Bushing
