BRAKE HARDWARE
BRAKE SHOE ANCHOR PINS
BRAKE SHOE ANCHOR PINS — OTHER
EUCLID NO.
REPLACES
LENGTH O.D.
“A” HEAD DIA.
APPLICATION
E-3870
Dayton/Batco 01451
Meritor 1259X1012
Sirco B950
Haldex C69611
Leland L2930
2-11/16” 13/16”
1-1/4” For Meritor 15” x 4” Front
“Q” Brake. Black Finish
E-3424
Dayton/Batco 01437
Meritor 1259B262
Dana/Spicer 15550
Navistar 482438C1
Haldex 66841
Wagner 914032
Haldex C66841
Leland L1736
Leland L754
2-3/4” 13/16” 17/32” 1-1/4”
For Meritor “T” Series 15” x
3-1/2” and 15” x 4” Type 1
and 2 Brakes. Available in
Brake Kit E-4691. Zinc Clear
Chromate Plated
E-3445
Dayton/Batco 01430
Navistar 142739R1
Dana/Spicer 15554
Meritor 1759Z26
Haldex C63073
3-5/16” 13/16” 7/8”
Eccentric Pin. For Meritor
“T” Series 16-1/4” x 3-1/2”
Brake. Zinc Clear Chromate
Plated
E-2798
Dayton/Batco 01446
Dana/Spicer 15557
Wagner 80414
Sirco B898
Haldex C66879
Wagner F80414
Leland L1675
Meritor R547022
3-5/16” 1-3/16” 1/2” 1-3/8”
For 15” x 4” with Wagner
Brakes. Use with E-4961A
Nut and E-2723 Snap Ring.
Available only in Brake Kit
E-3291. Zinc Clear Chromate
Plated
BRAKE HARDWARE
FOR BRAKE ANCHOR PINS, ROLLERS AND ROLLER PINS
EUCLID NO.
O.D.
I.D.
THICK
DIM.
BETWEEN LEG
OPENING HEIGHT
REPLACES
GENERAL INFORMATION
E-1106
5/8” 1-11/32”
Dayton/Batco 01493
Dana/Spicer 11527
Meritor 1229M221
Dana/Spicer 341535
Standard Forge
403104
Haldex 65561
Haldex 66544
Haldex C65561
Leland L1755
Leland L455
Dana/Spicer
M10HN154
Anchor Pin Lock
Washer for Std.
Forge 12-1/4” Dia.
Trailer Brakes and
Meritor 16-1/4” “T”
Series Steering Axle
Brake
E-671
1-11/16” 1-1/4” 17/32”
Dayton/Batco 01471
Dana/Spicer 351578
Haldex 65425
Leland L334
Eaton M1561
Meritor R547032
Anchor Pin Felt
Retainer for use
with E-521 and
E-608 Anchor Pins.
Available in Brake Kit
E-2676
