BRAKE HARDWARE
RETURN SPRINGS
FOR 16-1/2” BRAKES
EUCLID NO.
REPLACES
LENGTH
O.D.
GENERAL INFORMATION
E-3490B
Dayton/Batco 01379
Dayton/Batco 1346
Dayton/Batco 1369
Dana/Spicer 19853A
Meritor 2258U619
Meritor 2258W803
Trailmobile 383490B
Haldex 66565
Trailmobile 7007225
Trailmobile 700795
Wagner 914114
Fruehauf ACE009911PKG
Fruehauf ACF006414001
Holland Hitch ACF64141
Sirco B349
Leland L2370
Dana/Spicer M16WJ100
Meritor R567010
8-3/8”
1-1/4”
100 lb. “Mega Plus” spring.
Heavy-Duty Version of
E-2768 and E-3228. Use for
Meritor Q Plus™
E-3490S
Leland 2370
Leland L2370
8-3/8”
1-1/4”
Heavy-Duty wire, 80 lb.
tension, not shot-peened.
Found in “Stopmate Plus”
Brake Repair Kits. Same
applications as
E-3490B.
E-8907
Dayton/Batco 01-3862
Dayton/Batco 13862
Eaton 810292
Sirco B350
Haldex C63047
Leland L3118
Meritor R567022
8-13/32” 1-1/8”
For Eaton 16-1/2” x 7” “ES”
Severe Service Brake with
fabricated shoes and Eaton
“Top Spec ES” retrofit for
Fruehauf and Meritor brakes.
E-9069
Dayton/Batco 01372
Dana/Spicer 19913
Meritor 2258S643
Sirco B347
Haldex C63045
Leland L1383
Leland L3183
8-9/16”
1-1/8”
Bent Center Bar for Meritor
16-1/2” Front “Q” Brakes on
“FL” Series Axles
E-543
Dayton/Batco 01323
Dana/Spicer 19878
Fruehauf 219311
Meritor 2258K349
Meritor 2258R349
Trailmobile 44750
Navistar 56109R1
Haldex 65309
Trailmobile 7-8-22
Sirco B974
Haldex C66614
Leland L115
9”
1-1/8”
Used on 16-1/2” x 6” x 7”
Shoes. Also 18” x 7” Brakes
with Cast Shoe.
E-9643
Dayton/Batco 01-3751
Dayton/Batco 01375
Dayton/Batco 13751
Dana/Spicer 19910
Meritor 2258Y1273
Sirco B348
Sirco B871
Haldex C67320
Leland L2843
Leland L3126
9-1/16” 1-3/16”
For 16-1/2” Brakes with
relocated return spring shoes
and Q Plus™ camshafts. Can
also be used on “Hammer
Claw” camshafts
