CAMSHAFTS
CAMSHAFT TUBE ENCLOSURES FOR TRAILERS
EUCLID NO.
SPIDER
END I.D.
SUPPORT
END I.D.
TUBE OAL TUBE O.D.
CAM LENGTH
CAM APPLICATION
E-9591
1-1/2” 1-1/2” 14-3/4” 1-7/8”
17-5/16” For Meritor, Dana axles
E-10931
1-1/2” 1-1/2” 15”
1-7/8”
17-3/4” For Dana axles with 16-1/2” brake
E-9593
1-1/2” 1-1/2” 16”
1-7/8”
18-5/8” For Meritor, Dana, IMT- Eaton axles
E-4737A
1-1/2” 1-1/2” 17-3/4” 1-7/8”
20-3/8” For standard 1-1/2” dia. camshaft
E-10934
1-1/2” 1-1/2” 18-1/4” 1-7/8”
21-1/2” For Dana axles with 12-1/4” brake
E-9597
1-1/2” 1-1/2” 18-1/2” 1-7/8”
21-1/8” For Dana axles with 12-1/4” brake
E-10932
1-1/2” 1-1/2” 19-5/16” 1-7/8”
22-1/16” For Dana axles with 16-1/2” brake
E-10933
1-1/2” 1-1/2” 20-1/4” 1-7/8”
23-1/4” For Dana axles with 12-1/4” brake
E-9596
1-1/2” 1-1/2” 20-1/2” 1-7/8”
23-1/4” For Dana axles with 12-1/4” brake and air ride suspension
E-4738A
1-1/2” 1-1/2” 20.75”
1-7/8”
23-3/4” For standard 1-1/2” dia. camshafts with air ride suspension
E-9594
1-1/2” 1-1/2” 21”
1-7/8”
23-3/4” For Dana axles with Chalmers air ride
E-10936
1-1/2” 1-1/2” 23-1/2” 1-7/8”
26-1/2” For Dana axles with 12-1/4” brake
E-9590
1-1/2” 1-1/2” 23-1/2” 1-7/8”
26-5/8” For Standard Forge - IMT with air ride suspension
E-9592
1-1/2” 1-1/2” 23.52”
1-7/8”
26-1/4” For Dana wide track axles with air ride suspension
E-10937
1-1/2” 1-1/2” 23-7/8” 1-7/8”
26-1/16” For Dana axles with 16-1/2” brake
E-5242A
1-5/8” 1-1/2” 14-13/16” 2”
17-5/16” For Meritor axles
E-9601
1-5/8” 1-1/2” 17”
2”
19-1/2” For Eaton axles
E-10939
1-5/8” 1-1/2” 17-5/8” 2”
20-5/8” For Dana axles with 16-1/2” brake
E-5243A
1-5/8” 1-1/2” 18”
2”
20-13/32” For Meritor axles
E-10940
1-5/8” 1-1/2” 18-1/2” 2”
21-1/2” For Dana axles with 12-1/4” brake and 1-5/8” journal dia. at head
E-10942
1-5/8” 1-1/2” 20-1/4” 2”
23-1/4” For Dana axles with 12-1/4” brake and 1-5/8” journal dia. at head
E-10943
1-5/8” 1-1/2” 20-5/8” 2”
23-5/8” For Dana axles with 16-1/2” brake
E-9602
1-5/8” 1-1/2” 21”
2”
23-3/4” For Eaton axles with air ride suspension
E-10944
1-5/8” 1-1/2” 21”
2”
24”
For Dana axles with 16-1/2” brake
E-5244A
1-5/8” 1-1/2” 21.75”
2”
24-1/16” For Meritor axles
E-10945
1-5/8” 1-1/2” 23-1/2” 2”
26-1/2” For Dana axles with 12-1/4” brake and 1-5/8” journal dia. at head
E-4934A
1-5/8” 1-5/8” 13-3/4” 2”
16-1/8” For Fruehauf axles
E-5241A
1-5/8” 1-5/8” 19”
2”
21-1/8” For Fruehauf axles with air ride suspension
E-5240A
1-5/8” 1-5/8” 21-1/8” 2”
23-7/8” For Fruehauf axles with air ride suspension
E-9600
1-7/8” 1-1/2” 13-5/8” 2”
17-5/16” For Meritor axles with fabricated spiders and bolt-on bushings
E-9598
1-7/8” 1-1/2” 16-3/4” 2”
20-13/32” For Meritor axles with fabricated spiders and bolt-on bushings
E-9599
1-7/8” 1-1/2” 20-1/2” 2”
24-1/16” For Meritor axles with fabricated spiders and bolt-on bushings
E-11497
2”
1-1/2” 8 13/16”
11-1/16” Fore Intraax with 2” spider hole
