WHEEL END
WHEEL STUDS
“D” HEAD STUDS - Stud Body Diameter .910
EUCLID NO.
REPLACES
A
B
C GR.
E-8952-L
Conmet 101773
Motor Wheel 90442
Volvo TDA E8952L
Leland W627
3.16” 1.19” 1.25” 8
E-8952-R
Conmet 101774
Motor Wheel 90441
Leland W626
“D” HEAD STUDS - Stud Body Diameter 1.224 - Plain Body
EUCLID NO.
REPLACES
A
B
C GR.
E-8950-L
Conmet 100149
Conmet 100264
Leland W531
NWRA X2207
3.72” 1.50” 1.75” 8
E-8950-R
Conmet 100148
Conmet 100265
Leland W530
NWRA X2206
WHEEL STUDS — METRIC
Grade 10.9 (metric equivalent of Grade 8)
METRIC ROUND COLLAR SHOULDER STUDS - Stud Body Diameter .781
EUCLID NO.
REPLACES
A
B
C
D
E
F
E-11724
Meritor 09002073
5.54” 2.89” 1.64” 2.56” 2.25” .09”
E-11725
Meritor 09002140
6.40” 2.89” 1.43” 3.43” 3.11” .09”
METRIC CLIPPED “D” HEAD STUDS - Stud Body Diameter .888 - For Dura-Light Hubs
EUCLID NO.
REPLACES
A
B
C GR.
E-10256
Leland W770
3.38” .50” 2.50” 10.9
E-10257
Leland W759
4.19” .50” 3.31” 10.9
METRIC CLIPPED HEAD STUDS - Stud Body Diameter .907 - Plain Body
EUCLID NO.
REPLACES
A
B
C
D GR.
E-11693
Meritor 09001962
3.50” .94” .45” .31” 10.9
E-11692
Meritor 09001914
4.37” .95” .45” .31” 10.9
