ISUZU FRONT DRUM BRAKE 410MM X140MM
ISUZUFRONTDRUM BRAKE 410MM X140MM
PART NO.
DESCRIPTION
NOTES
E-7392
SPRING KIT
Springs — 2
Spring Color — Black
E7394
BRAKE SHOE ADJU
2 per axle
Clockwise Adjuster Cam — 1
Counterclockwise Adjuster Cam — 1
Adjuster Cam Spring — 2
Adjuster Cam Boot — 2
Spindle Pin — 2
Cam Guide Pin — 2
E-7396
Anchor Pin Service
Kit
2 per axle
Anchor Pins — 2
Brake Shoe Bushings — 2
Lock Washer — 1
Lock Bolt — 1
E-12657
BRAKE SHOE
E-7389 Brake Shoe lined with Euclid
E31 non-asbestos Brake Block.
FMSI Shoe No. — S613
FMSI Lining No. — 1418
Rivet — -
Size — 410mm x 140mm Manual
(16.142 x 5.512)
E-7398
WHEEL CYLINDER
Bleeder Screw — Yes
LH/RH — LH Front
Brake Diameter — 410mm x 140mm
E-7397
WHEEL CYLINDER
Wheel cylinder includes pipe joint,
pipe joint bolt, gasket and piston.
LH/RH — RH Front
Bleeder Screw — Yes
Brake Diameter — 410mm x 140mm
E-7399
WHEEL CYLINDER
Includes: 2 Piston Seals 2 Dust Boot
Seals 2 Back-up Rings
Brake Diameter — 410mm x 140mm
Wheel Cylinder Diameter — 47.5mm
Piston Seals — 2
Dust Boot Seals — 2
Back-up Rings — 2
