CALIPER INFORMATION CHART
CALIPER INFORMATIONCHART
CALIPER INFORMATIONCHART
3.094” (3 3/32”) Diameter Single Piston
LEFT HAND
RIGHT HAND
E-9152X
E-9151X
Disc Pad Set No.
Hardware Kit
Application
Notes
E-9152X
Brake Hose Inlet: 7/16-20
3.150” (80mm) Diameter Single Piston
LEFT HAND
RIGHT HAND
E-9172X
E-9171X
Disc Pad Set No.
Hardware Kit
Application
Notes
E-9172X
E-7930 (Services one axle)
Chevrolet, GMC
Brake Hose Inlet: 3/8-16
3.156” (3 5/32”) Diameter Single Piston
LEFT HAND
RIGHT HAND
E-9194X
E-9193X
Disc Pad Set No.
Hardware Kit
Application
Notes
E-9194X
E-7925 (Services one axle)
Chevrolet, GMC
Brake Hose Inlet: M10 x 1.5
