ABS
ABS
PART NO.
DESCRIPTION
NOTES
E-12293
SENSOR SPRING C
Outside Diameter 2 — 18.0mm
Inside Diameter 1 — 0.63”
Note — Holds the wheel speed sensor
inclose proximity to the tooth wheel.
Length 1 — 1.18”
Length 2 — 30.0mm
Inside Diameter 2 — 16.0mm
E-12294
SENSOR
Note — Typically used in heavy front axle
applications (16,000 to 20,000 GAWR).
Meters — 1.8
Style — Straight
Replaces 1 — S441 032 576 0
Replaces 2 — S441 032 602 0
Meters — 1.8
Feet — 5.8
Function — Installed at wheel ends to
measure the motion of a sensed wheel in
ABS.
E-12295
SENSOR
Note — FUNCTION :Installed at wheel ends
to measure the motion of a sensed wheel
in ABS. STYLE:Meritor WABCO sensors are
either straight or 90 deg pencil-type
sensors. Straight sensors are typically
used in heavy front axle applications
(16,000 - 20,000 GAWR) — 90
Meters — 1.8
Style — 90 degree
Replaces 1 — S441 032 057 0
Replaces 2 — S441 032 617 0
Meters — 1.8
Feet — 5.8
Function — Installed at wheel ends to
measure the motion of a sensed wheel in
ABS.
