MERITOR HYDRAULIC DISC BRAKE
MERITORHYDRAULICDISCBRAKE
PART NO.
DESCRIPTION
NOTES
E-4205
HARDWARE KIT
Services one wheel Use E-4208
Guide Bolt with this configuration
(1976-1985). Note: Pad Retainer
Spring 7 Long
E-7130
GUIDE PIN KIT
Services one wheel. Replaces E-4208
Guide Bolt, Support Key and Spring
from E-4205 (1986-1995). Note:
Pad Retainer Spring 7 Long
E-4206
SEAL KIT
Seals — 2
Boots — 2
E-4207
PISTON
Piston Type — Aluminum
Diameter — 2.181”
E-D120-S
STOPMATE DISC
FMSI Disc Pad No. — D120
FMSI No. — 7054-D120
Inner Pad Backing Plate Length —
7.5625
Inner Pad Lining Length — 7.4375
Outer Pad Backing Plate Length —
7.5625
Outer Pad Lining Length — 7.4375
