MERITOR HYDRAULIC DISC BRAKE
MERITORHYDRAULICDISCBRAKE
PART NO.
DESCRIPTION
NOTES
E-11729
HARDWARE KIT
Services one Wheel
Lining Spacer Bolt — 2
Anti-Rattle Spring — 1
Lining Spacer — 2
Bolt — 1
E-11730
SEAL KIT
Boot — 4
Seals — 4
E-11783
PISTON
Piston Type — Phenolic
Diameter — 70mm
Comment — When using phenolic
order Seal Kit E-11730
E-D769-S
DISC BRAKE PAD
FMSI No. — 7636-D769
Backing Plate Thickness — .25
Backing Plate Length — 9.4313”
Outer Pad Backing Plate Length —
9.4531”
