2-34
CANADA - 800-387-3889
LUCAS BACKING PLATE ASSEMBLIES
LUCASBACKINGPLATEASSEMBLIES
PART NO.
DESCRIPTION
NOTES
E-9422X
REMAN LH PLATE
Application — Left Hand Assembly with 1
3/4” Wheel Cylder and Expander for 6” and
7 “Brakes
E-9423X
REMAN RH PLATE
Application —Right Hand Assembly with 1
3/4” Wheel Cylder and Expander for 6” and
7” Brakes
E-9424X
REMAN LH PLATE
Application — Left Hand Assembly with 1
3/4” Wheel Cylder and Expander for 5”
Brakes Important Note: The 1 3/4”
assembly is a retrofit for the 1 5/8”
assembly, usually used on the 15” x 5”
brake. When retrofittg to 1 3/4”, you must
do both
E-9425X
REMAN RH PLATE
Application — Right Hand Assembly with1
3/4 Wheel Cylder and Expander for 5”
Brakes Important Note: The 1 3/4”
assembly is a retrofit for the 1 5/8”
assembly, usually used on the 15” x 5”
brake. When retrofittg to 1 3/4”, you must
do both
E-11824X
AY-LH BACK PLT
Cylinder Bores — 1.75”
Application — Left Hand New Backing
Assembly with Shoes. 15”x 5” x 1.75”
55.93 lbs.
E-11825X
AY-RH BACK PLT
Cylinder Bores — 1.75”
Application — Right Hand New Backing
Assembly with Shoes.15”x 5” x 1.75”
55.93 lbs.
E-11826X
AY-LH BACK PLT
Application — Left Hand New Backing
Assembly with Shoes .15”x 5” x 1.75”
58.70 lbs.
Cylinder Bores — 1.75”
E-11827X
AY-RH BACK PLT
Cylinder Bores — 1.75”
Application — Right Hand New Backing
Assembly with Shoes .15”x 5” x 1.75”
5 58.70 lbs.
E-11828X
AY-LH BACK PLT
Application — Left Hand New Backing
Assembly with Shoes .15”x 5” x 1.75”
61.73 lbs.
Cylinder Bores — 1.75”
E-11829X
AY-RH BACK PLT
Cylinder Bores — 1.75”
Application — Right Hand New Backing
Assembly with Shoes .15”x 5” x 1.75”
61.73 lbs.
