WAGNER REAR BRAKE (ALL)
WAGNERREARBRAKE (ALL)
WAGNERREARBRAKE (ALL)
A
C
B
Contained in Hold Down
Kit E-4144
Contained in Guide Bolt
Kit E-4145
Contained in Adjuster Kits
See Pg. 4-39
MANUAL ADJUSTMENT
FMSI
FMSI
BRAKE
LINING
SHOE
SIZE
1252
377
15" x 5"
1254
385
16" x 5"
1255
386
16" x 6"
4596
380
15" x 6"
4597
382
15" x 7"
4645A
375
15" x 4"
E-4078
E-4062
E-4027, E-4212
(SPRING KIT)
E-4027, E-4212
(SPRING KIT)
A
A
A
A
A
B
A
B
A
B
A
B
A
B
A
B
C
C
C
E-4062
E-4078
A
B
E-4050 (15" BRAKE)
E-4051 (16" BRAKE)
E-4050 (15" BRAKE)
E-4051 (16" BRAKE)
C
C
C
EUCLID
UNLINED
SHOE
SIZE
FMSI NO.
E-2529
15" x 5"
1252-377
N/A
E-2498
E-2499
N/A
N/A
16" x 6"
15" x 6"
15" x 7"
15" x 4"
16" x5"
1255-386
4596-380
4597-382
4645A-375
1254-385
