2-51
WAGNER HARDWARE PARTS
WAGNERHARDWAREPARTS
PART NO.
DESCRIPTION
NOTES
E-4068
ADJUSTER SCREW
Remove ring for manual applications.
Brake Diameter — 15”
Application — For Wagner 15” Rear Brake
Front/Rear — Rear
LH/RH — (RH)
Overall Length — 1.63”
E-4067
ADJUSTER SCREW
Remove ring for manual applications.
Overall Length — 1.63”
Application — For Wagner 15” Rear Brake
Brake Diameter — 15”
Front/Rear — Rear
LH/RH — (LH)
E-4072
ADJUSTER SCREW
Remove ring for manual applications.
Front/Rear — Rear
LH/RH — (RH)
Brake Diameter — 16”
Overall Length — 1.75”
Application — For Wagner 16” Rear Brake
E-4071
ADJUSTER SCREW
Remove ring for manual applications.
LH/RH — (LH)
Overall Length — 1.75”
Application — For Wagner 16” Rear Brake
E-4077
ANCHOR
Adjustment — Automatic
Application — 15” X 6”, 15” X 7”
Brake Diameter — 15” x 6”, 15” x 7”
Slot Widths — .500
Overall Length — 2”
Front/Rear — Rear
E-4062
ANCHOR
Adjustment — Automatic
Overall Length — 1.31
Application — 15” x 5”, 15” x 6”, 15” x 7”
Front/Rear — Rear
Slot Widths — .500
Brake Diameter — 15” x 5”, 15” x 6”, 15”
x 7”
E-4050
STAR WHEEL
Front/Rear — Rear
Adjustment — Manual
Application — All Wagner 15” Rear
Brakes
Teeth — 16 Teeth
Brake Diameter — 15”
E-4051
STAR WHEEL
Brake Diameter — 16”
Adjustment — Manual
Application—All Wagner 16” Rear Brakes
Teeth — 18 Teeth
Front/Rear — Rear
