Firestone Catalog

1T14C-3

8.2

Watson & Chalin

AS-0069

W01-358-5433

1T14C-3

3136

7.3

Granning 7765

W01-358-5434

1T14C-3

3386

7.4

Granning 7831

W01-358-5436

1T14C-3

3136

6.8

Granning 6250

W01-358-9478

1T14C-5

3136

8.8

General Coach

W01-358-5335

BELLOW NO.

ASSEMBLY

ORDER NO.

CROSS SECTION VIEW BEAD PLATE

TOP VIEW

PISTON

BOTTOM VIEW

ASSEMBLY

WEIGHT

(lbs.)

REPLACES

No Alignment Specified-Center Stud Mounting is Standard

Bolt or Stud 1/2-13

Combination Stud/Air Inlet Stud Outside Thread is 3/4-16

Threaded Hole 3/8-16 Blind Nut on Bead Plates 1/2-13 Pistons

Air Inlet 1/4 N.P.T.

Studs Inside Thread (Air Inlet) is 1/4 N.P.T. Exceptions WIll Be Noted on Part View as

Hardware Key
