145 / 257
W02-358-7031
7014
7049
7.00"
1.3
MACK
227QS33
GY 1S4-007
NBD-10082
NBD-10549 GREEN
W02-358-7209
7042
6979
7.00"
1.3
SEATS
708220
(W02-812-7209)
NBD-10409
FIP-100105 GREEN
W02-358-7106
6997
9637
9.87"
1.2
LINK
MANUFACTURING
LTD
1102-0030 (PETE.)
NBD-13262
FIP-102215 GREEN
W02-358-7085
7013
7023
11.5"
N/A
AIR FLEX
(W02-A05-7085)
NBD-10183
NBD-10071 GREEN
ASSEMBLY
ORDER NO.
CROSS SECTION VIEW
CAP
DRAWING
NUMBER
PISTON
DRAWING
NUMBER
BCR
LOGO
COLOR
ASSEMBLY
WEIGHT
(lbs.)
APPLICATIONS
INF. - Inflated (Max.) / UNINF. - Uninflated / (P) - Plastic / (AL) - Aluminum / BCR - Between Clamp Rings / N/A - Not Available
144
