36 / 257
1T15M-2
5681
14.3
Ridewell
1003588930C
W01-358-8930
SERVICE ASSEMBLY
W01-358-0725
1T15M-2
3159
15.8
John Deere
W01-358-8931
METRIC
1T15M-2
5681
12.7
Reyco 22241-01
W01-358-8932
1T15M-2
5681
10.9
Hendrickson Trailer
S20228
W01-358-8934
1T15M-2
5687
OBSOLETE
NO LONGER AVAILABLE
12.1
Tuthill Reyco
23027-01
W01-358-8935
OBSOLETE
1T - Reversible Sleeve
BELLOW NO.
ASSEMBLY
ORDER NO.
CROSS SECTION VIEW BEAD PLATE
TOP VIEW
PISTON
BOTTOM VIEW
ASSEMBLY
WEIGHT
(lbs.)
REPLACES
No Alignment Specified-Center Stud Mounting is Standard
Bolt or Stud 1/2-13
Combination Stud/Air Inlet Stud Outside Thread is 3/4-16
Threaded Hole 3/8-16 Blind Nut on Bead Plates 1/2-13 Pistons
Air Inlet 1/4 N.P.T.
Studs Inside Thread (Air Inlet) is 1/4 N.P.T. Exceptions WIll Be Noted on Part View as
Hardware Key
35
1T Style Springs
