26 / 68
24
I – Inboard Mount
O – Outboard Mount
X – Balanced
(tp) – Patented TruPilot Feature
(a) – Unequally spaced exciter ring mounting
(b) – Equally spaced exciter ring mounting
(c) – Peripheral mount pilot
(d) – Furnished with set screw holes
(e) – Notched
(f) – For ball seat or hub piloted applications
(o) – OEM captive part number
Active Part Numbers
In Order by Part Number
Active Part Numbers
In Order by Size
Obsolete Part Numbers
In Order by Part Number
Gunite
No.
Drum
Weight
Drum
Mount
Drum
Type
Wheel
Type
Brake Size
Overall
Depth
Width
of Brake
Surface
Pilot
Dia.
Bolt
Circle
Dia.
Bolt Holes
Special Information
No.
Size
2997BX 107
I
AAA Spoke
16.50x7.00
8.74
7.58 10.50 12.75
5
0.78
2997C 107
I
AAA Spoke
16.50x7.00
8.74
7.58 10.50 12.75
6
0.78
2997CX 107
I
AAA Spoke
16.50x7.00
8.74
7.58 10.50 12.75
6
0.78
2997DX 107
I
AAA Spoke
16.50x7.00
8.74
7.58 10.50 12.75
5/6
0.78
2997X 107
I
AAA Spoke
16.50x7.00
8.74
7.58 10.50 12.75
5
0.78 Unequally spaced exciter
ring mounting.
2999 90
I
AAA Spoke
15.00x6.00 7.04
6.40 9.00 11.25
5
0.78
Equally spaced exciter
ring mounting.
2999X 90
I
AAA Spoke
15.00x6.00 7.04
6.40 9.00 11.25
5
0.78
Equally spaced exciter
ring mounting.
3002
82
I
ABG Spoke
16.50x5.00 6.56 5.40 9.00 11.25
5
0.78
Equally spaced exciter
ring mounting.
3002B 82
I
ABG Spoke
16.50x5.00 6.56 5.40 9.00 11.25
5
0.78
3002BX 82
I
ABG Spoke
16.50x5.00 6.56 5.40 9.00 11.25
5
0.78
3002X 82
I
ABG Spoke
16.50x5.00 6.56 5.40 9.00 11.25
5
0.78
Equally spaced exciter
ring mounting.
3005
85
I
AAA Spoke
15.00x6.00 8.24
6.53 10.50 12.75
5
0.78 Unequally spaced exciter
ring mounting.
3005A 85
I
AAA Spoke
15.00x6.00 8.24
6.53 10.50 12.75
5
0.78
3005AX 85
I
AAA Spoke
15.00x6.00 8.24
6.53 10.50 12.75
5
0.78
3005X 85
I
AAA Spoke
15.00x6.00 8.24
6.53 10.50 12.75
5
0.78 Unequally spaced exciter
ring mounting.
3007
80
I
ABA Spoke
15.00x5.00 6.54
5.40 9.00 11.25
5
0.78
Equally spaced exciter
ring mounting.
3007X 80
I
ABA Spoke
15.00x5.00 6.54
5.40 9.00 11.25
5
0.78
Equally spaced exciter
ring mounting.
3012
109
I
ABI
Spoke
16.50x7.00 8.94
7.62 9.50 11.25
5
0.81
3012A 109
I
ABI
Disc
16.50x7.00 8.94
7.62 9.50 11.25
10
0.81
Un-notched use 3018A.
3012AX 109
I
ABI
Disc
16.50x7.00 8.94
7.62 9.50 11.25
10
0.81
3012B 109
I
ABI
Spoke
16.50x7.00 8.94
7.62 9.50 11.25
5/6
0.78
3012BX 109
I
ABI
Spoke
16.50x7.00 8.94
7.62 9.50 11.25
5/6
0.78
3012X 109
I
ABI
Spoke
16.50x7.00 8.94
7.62 9.50 11.25
5
0.81
3013
54
I
AAA Spoke
15.00x3.50 4.56 3.94 9.00 10.50
5
0.53 Unequally spaced exciter
ring mounting.
3013A 54
I
AAA Spoke
15.00x3.50 4.56 3.94 9.00 10.50
5
0.53
3013AX 54
I
AAA Spoke
15.00x3.50 4.56 3.94 9.00 10.50
5
0.53
3013X 54
I
AAA Spoke
15.00x3.50 4.56 3.94 9.00 10.50
5
0.53 Unequally spaced exciter
ring mounting.
3015
85
I
AAA Spoke
16.50x5.00 6.06 5.37
9.25 11.25
5
0.78 Unequally spaced exciter
ring mounting.
3015X 85
I
AAA Spoke
16.50x5.00 6.06 5.37
9.25 11.25
5
0.78 Unequally spaced exciter
ring mounting.
3016
91
I
ABJ Spoke
15.00x6.00 8.78 6.62 9.75 11.25
5
0.78
3016X
91
I
ABJ Spoke
15.00x6.00 8.78 6.62 9.75 11.25
5
0.78
3018
114
I
ABA Spoke
16.50x7.00
8.74
7.50 9.50 11.25
5
0.81
3018AX 113
I
ABA Spoke/
Disc
16.50x7.00
8.74
7.50 9.50 11.25
10
0.81
For severe duty use
3564AX.
3018B 114
I
ABA Spoke
16.50x7.00
8.74
7.50 9.50 11.25
6
0.78
3018BX 114
I
ABA Spoke
16.50x7.00
8.74
7.50 9.50 11.25
6
0.78
3018C
114
I
ABA Spoke
16.50x7.00
8.74
7.50 9.50 11.25
5
0.81
3018C
114
I
ABA Spoke
16.50x7.00
8.74
7.50 9.50 11.25
6
0.65
3018CX 114
I
ABA Spoke
16.50x7.00
8.74
7.50 9.50 11.25
5
0.81
3018CX 114
I
ABA Spoke
16.50x7.00
8.74
7.50 9.50 11.25
6
0.65
3018D 114
I
ABA Spoke
16.50x7.00
8.74
7.50 9.50 11.25
6
0.81
3018D 114
I
ABA Spoke
16.50x7.00
8.74
7.50 9.50 11.25
6
0.65
3018DX 114
I
ABA Spoke
16.50x7.00
8.74
7.50 9.50 11.25
6
0.65
3018DX 114
I
ABA Spoke
16.50x7.00
8.74
7.50 9.50 11.25
6
0.81
3018X 114
I
ABA Spoke
16.50x7.00
8.74
7.50 9.50 11.25
5
0.81
