40 / 68
38
I – Inboard Mount
O – Outboard Mount
X – Balanced
(tp) – Patented TruPilot Feature
(a) – Unequally spaced exciter ring mounting
(b) – Equally spaced exciter ring mounting
(c) – Peripheral mount pilot
(d) – Furnished with set screw holes
(e) – Notched
(f) – For ball seat or hub piloted applications
(o) – OEM captive part number
Active Part Numbers
In Order by Part Number
Active Part Numbers
In Order by Size
Obsolete Part Numbers
In Order by Part Number
Gunite
No.
Drum
Weight
Drum
Mount
Drum
Type
Wheel
Type
Brake Size
Overall
Depth
Width
of Brake
Surface
Pilot
Dia.
Bolt
Circle
Dia.
Bolt Holes
Special Information
No.
Size
3564A 122
I
ABA Spoke/
Disc
16.50x7.00
8.74
7.50 9.50 11.25
10
0.81
Severe duty version of
3018A.
3564AX 122
I
ABA Spoke/
Disc
16.50x7.00
8.74
7.50 9.50 11.25
10
0.81
Severe duty version of
3018AX.
3568 (o)
112
O BBA Disc
16.50x7.00 10.54 7.60 8.78 11.25
10
1.00
3568A
(o)
112
O BBA Disc
16.50x7.00 10.54 7.60 8.78 11.25
10
1.00 With brake surface wear
indicator.
3568AX
(o)
112
O BBA Disc
16.50x7.00 10.54 7.60 8.78 11.25
10
1.00 With brake surface wear
indicator.
3568X
(o)
112
O BBA Disc
16.50x7.00 10.54 7.60 8.78 11.25
10
1.00
3569X
(o)
79
O BEA Disc
15.00x4.00 8.87
4.48 8.78 11.25
10
1.25
3570 (o)
112
O BDA Disc
16.50x7.00 10.54 7.46 8.78 11.25
10
1.25
3570A
(o)
112
O BDA Disc
16.50x7.00 10.54 7.46 8.78 11.25
10
1.25
3570AX
(o)
112
O BDA Disc
16.50x7.00 10.54 7.46 8.78 11.25
10
1.00
3570X
(o)
112
O BDA Disc
16.50x7.00 10.54 7.46 8.78 11.25
10
1.25
3574
80
O BEA Disc
15.00x4.00 9.18
4.41
8.53 11.25
10
1.25
3574A 80
O BEA Disc
15.00x4.00 9.18
4.41
8.78 11.25
10
1.00
3574AX 80
O BEA Disc
15.00x4.00 9.18
4.41
8.78 11.25
10
1.00
3574B 80
O BEA Disc
15.00x4.00 9.18
4.41
8.78 11.25
10
1.25
3574BX 80
O BEA Disc
15.00x4.00 9.18
4.41
8.78 11.25
10
1.25
3575
79
O BEA Disc
15.00x4.00 8.79 4.40 8.78 11.25
10
1.25
3575X 79
O BEA Disc
15.00x4.00 8.79 4.40 8.78 11.25
10
1.25
3576A 131
O BDA Disc
16.50x7.00 10.54 7.60 8.78 11.25
10
1.25
3576AX 131
O BDA Disc
16.50x7.00 10.54 7.60 8.78 11.25
10
1.25
3578
116
O BDA Disc
16.50x7.00 10.59 7.75 9.00 11.25
10
0.81
Severe duty version of
3141.
3578X 116
O BDA Disc
16.50x7.00 10.59 7.75 9.00 11.25
10
0.81
Severe duty version of
3141X.
3580
118
I
ABA Spoke
16.50x7.00
8.74
7.50 9.50 11.25
5
0.81
3580A 118
I
ABA Spoke
16.50x7.00
8.74
7.50 9.50 11.25
10
0.81
3580AX 118
I
ABA Spoke
16.50x7.00
8.74
7.50 9.50 11.25
10
0.81
3580X 118
I
ABA Spoke
16.50x7.00
8.74
7.50 9.50 11.25
5
0.81
3593
112
O BBA Disc
16.50x7.00 10.54 7.60 8.78 11.25
10
1.00
3593X 112
O BBA Disc
16.50x7.00 10.54 7.60 8.78 11.25
10
1.00
3595
98
O BDA Disc
16.50x5.00 8.02 5.40 8.78 11.25
10
1.25
3595A 98
O BDA Disc
16.50x5.00 8.02 5.40 8.78 11.25
10
1.00
3596 79
O BEH Disc
15.00x4.00 8.65 4.40 8.78 11.25
10
1.25
3596A 79
O BEH Disc
15.00x4.00 8.65 4.40 9.00 10.82
8
1.00
3596AX 79
O BEH Disc
15.00x4.00 8.65 4.40 9.00 10.82
8
1.00
3596B 79
O BEH Disc
15.00x4.00 8.65 4.40 8.78 11.25
10
1.00
3596C 79
O BEH Disc
15.00x4.00 8.65 4.52
8.78 11.25
10
1.25
3596CX 79
O BEH Disc
15.00x4.00 8.65 4.52
8.78 11.25
10
1.25
3597
84
O BEA Disc
15.00x5.00 9.31
5.40 8.78 11.25
10
1.25
3597A 84
O BEA Disc
15.00x5.00 9.31
5.40 9.00 10.82
8
1.00
3597AX 84
O BEA Disc
15.00x5.00 9.31
5.40 9.00 10.82
8
1.00
3597B 84
O BEA Disc
15.00x5.00 9.31
5.40 8.78 11.25
10
1.00
3597BX 84
O BEA Disc
15.00x5.00 9.31
5.40 8.78 11.25
10
1.00
3597X 84
O BEA Disc
15.00x5.00 9.31
5.40 8.78 11.25
10
1.25
3598
96
O BDA Disc
16.50x5.00 9.34
5.40 8.78 11.25
10
1.25
3598A 96
O BDA Disc
16.50x5.00 9.34
5.40 9.00 10.82
8
1.00
3598AX 96
O BDA Disc
16.50x5.00 9.34
5.40 9.00 10.82
8
1.00
3598B 96
O BDA Disc
16.50x5.00 9.34
5.40 8.78 11.25
10
1.00
