I – Inboard Mount
O – Outboard Mount
X – Balanced
(tp) – Patented TruPilot Feature
(a) – Unequally spaced exciter ring mounting
(b) – Equally spaced exciter ring mounting
(c) – Peripheral mount pilot
(d) – Furnished with set screw holes
(e) – Notched
(f) – For ball seat or hub piloted applications
(o) – OEM captive part number
Active Part Numbers
In Order by Part Number
Active Part Numbers
In Order by Size
Obsolete Part Numbers
In Order by Part Number
Gunite
No.
Drum
Weight
Drum
Mount
Drum
Type
Wheel
Type
Brake Size
Overall
Depth
Width
of Brake
Surface
Pilot
Dia.
Bolt
Circle
Dia.
Bolt Holes
Special Information
No.
Size
3895X 79
O ADA Disc
15.00x5.00 8.03 5.71
6.25 8.75
6
0.81
3899 112
O BDA Disc
16.50x7.00 10.54 7.60 8.78 11.25
10
1.00
For use with LynnFin
cooling component.
3899X 112
O BDA Disc
16.50x7.00 10.54 7.60 8.78 11.25
10
1.00
For use with LynnFin
cooling component.
3926X 140
O BCH Disc
18.00x7.00 10.09 7.60 8.78 11.25
10
1.00
3927X 88
O BEA Disc
15.00x5.00 9.04 5.56 8.67
11.25
10
1.25
7000X 63
O BEG Disc
15.00x4.00 8.54 4.66 8.78 11.25
10
1.25
7001X
67
O BEG Disc
15.00x4.00 8.93 4.66 8.78 11.25
10
1.25
7002X 77
O BDG Disc
16.50x5.00 8.79 5.38 8.78 11.25
10
1.25
7003X 78
O BEG Disc
16.50x5.00 9.17
5.38 8.78 11.25
10
1.25
7004X 83
O BEG Disc
15.00x6.00 9.37
6.40 8.78 11.25
10
1.25
7005X 86
O BDG Disc
16.50x6.00 9.37
6.52 8.78 11.25
10
1.25
7006X 91
O BDA Disc
16.50x7.00 10.28 7.66 8.78 11.25
10
1.00
7007X 85
O BEA Disc
15.00x6.00 9.67
6.40 8.78 11.25
10
1.25
7008X 81
O BEA Disc
15.00x6.00 9.29 6.40 8.78 11.25
10
1.25
7009X 69
O BEA Disc
15.00x5.00
9.17
5.40 8.78 11.25
10
1.25
7010X
71
O BDA Disc
15.00x5.00 8.79 5.40 8.78 11.25
10
1.25
7011X
63
O BDA Disc
15.00x4.00 8.54
4.78 9.00 10.82
8
1.00
7012X
91
O BDA Disc
16.50x7.00 10.28 7.50 9.00 10.82
8
1.00
7013X
91
O BDA Disc
16.50x7.00 10.28 7.66 9.00 11.25
10
1.00
7014X
87
I
BDA Disc
16.50x7.00 9.50 7.56 9.44
11.25
10
0.84
7015X
85
I
BBA Disc
16.50x7.00
8.74
7.50 9.50 11.25
10
0.81
7016X
67
O BEA Disc
15.00x4.00 8.93 4.66 9.00 10.82
8
1.00
7017X
97
O BDC
Disc
15.00x8.62
11.65 9.30 8.78 11.25
10
1.00
7018X 98
O BDC
Disc
15.00x8.62
11.95 9.49 8.78 11.25
10
1.00
7019X 106
O BDA Disc
16.50x8.62
11.06 9.14
8.78 11.25
10
1.00
7020X 118
O BDA Disc
16.50x8.00 10.78 8.60 8.78 11.25
10
1.00
7021X
91
O BDA Disc
16.50x7.00 10.40 7.70 8.53 11.25
10
0.81
7022X 92
O BDA Disc
16.50x7.00 10.04 7.34
8.53 11.25
10
0.81
7023X 93
O BDA Disc
16.50x7.00 10.44 7.85 9.00 10.82
8
1.00
7024X 93
O BDA Disc
16.50x7.00 10.44 7.85 9.00 11.25
10
1.00
7025X 94
O BDA Disc
16.50x7.00 10.60 7.98 8.78 11.25
10
1.00
7026X 63
O BDA Disc
15.00x4.00 8.54
4.78 9.00 10.82
8
0.90
7027X 67
O BDA Disc
15.00x4.00 8.93 4.66 9.00 10.82
8
0.90
7028X 93
O BDA Disc
16.50x7.00 10.44 7.85 9.00 10.82
8
0.90
7029X 93
O BDA Disc
16.50x7.00 10.44 7.85 9.00 11.25
10
0.81
7030X 94
O BDA Disc
16.50x7.00 10.60 7.98 8.78 11.25
10
0.90
7031X
91
O BDA Disc
16.50x7.00 10.28 7.66 8.78 11.25
10
0.90
7032X 63
O BEA Disc
15.00x4.00 8.54
4.78 8.78 11.25
10
0.90
7033X 67
O BEA Disc
15.00x4.00 8.93 4.66 8.78 11.25
10
0.90
7034X 78
O BDG Disc
16.50x5.00 8.79 5.38 8.78 11.25
10
0.90
8014 (o)
135
I
ABD SPOKE
20.00x6.00 9.62
6.18 12.75 15.00
12
0.76
8014X
(o)
135
I
ABD SPOKE
20.00x6.00 9.62
6.18 12.75 15.00
12
0.76
8017 (o)
84
I
AAG Disc
17.25x5.00 6.50 5.62 11.25 12.87
12
0.78
8017X
(o)
84
I
AAG Disc
17.25x5.00 6.50 5.62 11.25 12.87
12
0.78
8028 (o)
98
I
CBA Spoke
16.50x7.00 8.56 7.50 14.25 12.75
6
0.64
8028X
(o)
98
I
CBA Spoke
16.50x7.00 8.56 7.50 14.25 12.75
6
0.64
8042 (o)
145
O BBD Disc
17.25x6.00 10.56 6.62 13.12
11.25
10
1.17
8042X
(o)
145
O BBD Disc
17.25x6.00 10.56 6.62 13.12
11.25
10
1.17
