Active Part Numbers
Obsolete Part Numbers
Footnotes: H – Hat-shaped rotor. (c) – Peripheral mount pilot.
U – U-shaped rotor.
(j) – Rotor pilots on rotor cap screws or rotor studs.
X – Balanced.
(o) – OEM captive part number.
Gunite
No.
Rotor
Weight
Rotor
Style
Brake Surface
Pilot
Dia.
Bolt
Circle
Dia.
Bolt Holes
Special Information
Outside
Dia.
Width
Overall
Length
No.
Size
R3064X 65.0 U 15.62 1.75
4.92
9.50 12.75 6 0.78
For Gunite TH-24 Air/Hydraulic.
D3312(o)
58.0 U 15.00 1.43
6.79 9.00 11.25 10 0.81
Aftermarket use D6145.
D6052 39.0 H 15.39 1.53
3.40
(j)
7.25 10 0.57
D6059 57.0
U 15.38 1.53
6.18 9.50 11.25 10 0.81
Bendix Hydraulic.
D6066(o)
50.0 U 15.00 1.43
4.49 9.00 11.25 5 0.65
D6066B(o)
50.0 U 15.00 1.43
4.49 9.00 11.25 5/6 0.78
D6071(o)
50.0 U 15.00 1.43
5.84
(j)
11.25 10 1.26
D6115
58.0 U 15.00 1.43
5.90
(j)
12.75 5 0.65
(c) Bendix Hydraulic.
D6115A 58.0 U 15.00 1.43
5.90
(j)
12.75 5 0.76
(c) Bendix Hydraulic.
D6121(o)
58.0 U 15.00 1.43
5.90
(j)
12.75 5 0.64
Aftermarket use D6115.
D6121A(o)
58.0 U 15.00 1.43
5.90
(j)
12.75 5 0.76
Aftermarket use D6115A.
D6145(o)
58.0 U 15.00 1.43
6.80 9.00 11.25 10 0.81
D6147(o)
49.0 U 15.00 1.43
4.77
9.00 11.25 5 0.78
Aftermarket use D6168.
D6168 50.0 U 15.00 1.43
4.77
9.00 11.25 5 0.78
D6176DM 39.0 H 15.00 1.43
3.21
(i)
7.25 6 0.57
With corrosion protection coating.
D6176M 39.0 H 15.00 1.43
3.21
(j)
7.25 10 0.57 ABS version of D6153. With corrosion protection
coating.
D6178M 59.0 U 15.00 1.43
7.11
9.50 11.25 10 0.81
ABS version of D6157. With corrosion protection
coating.
D6178AM 72.0
U 14.87
1.77
6.17
8.50 10.83 10 1.06
R6182(o)
72.0
U 14.87
1.77
6.17
8.50 10.83 10 1.25
R6182A(o)
72.0
U 14.87
1.77
6.17
8.50 10.83 8 1.06
D6183M 44.0
H 15.00 1.43
4.44
(j)
7.25 10 0.57 ABS version of D6133. With corrosion protection
coating.
D6194AM 34.0 H 15.00 1.43
3.50 5.40 6.75 6 0.76
With corrosion protection coating.
D6194M 34.0 H 15.00 1.43
3.50 5.40 6.75 6 0.57
With corrosion protection coating.
R6198 69.0 U 15.25 1.75
6.13
8.75 11.25 10 0.81
R6200 66.0 U 15.25 1.75
5.78
(j)
11.25 10 0.81
R6205 76.0
U 16.93 1.77
5.90 8.65 9.82 10 0.62
Air Disc Brake - Non-ABS.
R6206M 79.0 U 16.93 1.77
5.90 8.65 9.82 10 0.62
Air Disc Brake - ABS
(7.25 Dia Sensing circle).
