15 / 105
1-10
U.S. 888-725-9355
Canada 800-387-3889
ABS
TRAILER
RSS+ EXTENSIONS
PART NO.
FEET METERS
APPLICATION
S449 723 018 0
6
1.8
Use with RSS 2M only. Sensor extension cable with 90 degree
connector at the ECU. Plugs into standard Meritor WABCO ABS
sensors.
S449 723 030 0
9
3
Use with RSS 2M only. Sensor extension cable with 90 degree
connector at the ECU. Plugs into standard Meritor WABCO ABS
sensors.
S449 723 051 0
16 5.1
Use with RSS 2M only. Sensor extension cable with 90 degree
connector at the ECU. Plugs into standard Meritor WABCO ABS
sensors.
S441 050 100 0
Distance sensor used for mechanical coil spring applications.
IN-LINE FILTERS
PART NO.
APPLICATION
S432 500 005 0
In-line filter (complete valve). Mounted at the Gladhand. Highly recommended for
control line.
Prevents contamination of the trailer’s air system. Requires regular cleaning, but
equipped with a bypass if needed.
S884 490 307 4
Grease
S897 080 360 4
O-Ring
TOOLS
PART NO.
APPLICATION
S100 100 002 4
In-line filter tool (to clean and replace cartridge). For S432 500 005 0 only.
S100 100 101 0
Sensor Block Mounting Fixture for TP axles.
MBS2 retrofits will require the use of several available tools to assist in proper
installation. See TP-06110 for technical publication on the MBS-2 retrofit process.
S2237 Z 1222
A sealed switch and lamp that connects to the SAE J1587 diagnostic connector.
This tool is used to activate the Easy-Stop and Enhanced Easy-Stop blink code
diagnostics, configure the ECU, and test the installation. The tool is designed to
remain on the trailer at all times.
BRACKETS
PART NO.
APPLICATION
S478 407 058 4
For 2S/1M ECU/Valve assemblies only.
