28 / 105
U.S. 888-725-9355
MeritorPartsOnline.com
1-23
Canada 800-387-3889
ABS
SENSORS
BRACKETS
PART NO.
PER PACK
APPLICATION
2255 T 1346
4
Sensor Bracket used in current Meritor production trailer axle
manufacturing.
2255 U 1113
1
Sensor Bracket for TN, TQ, TP trailer axles
IMAGE NOT AVAILABLE
AT TIME OF PRINTING
S441 902 352 4
1
Sensor Connector for meeting support
BUSHING
PART NO.
INSIDE DIAMETER OUTSIDE DIAMETER
LENGTH
APPLICATION
S1225 S 1189
.71 in.
.87 in.
1.18 in.
Used on front steer axles
only.
PRESSURE SENSOR
PART NO.
PORT
RATING
APPLICATION
S441 044 106 0
1/4” NPTF
15 bar
Use with RSC, ESC, OnGuard and trailer
RSSplus System.
TONE RINGS
PART NO.
R955013
R955017
