VALVES
RELAY VALVES
RE-6 RELAY EMERGENCY VALVE
PART NO.
SERVICE PORT SUPPLY PORT DELIVERY PORT
R955281865
(1) 1/4 in.
(1) 3/8 in.
(1) 3/4 in.
(2) 1/4 in.
RELAY VALVE
PART NO.
SUPPLY PORT DELIVERY PORT
CONTROL
POSITION CRACK PRESSURE
PLUGS
INCLUDED
R955KN28500
RKN28500
(2) 3/8 in.
(2) 3/8 in.
90
o
5.6 psi
(1) 3/8 in.
RKN28510
(1) 3/8 in.
(1) 1/2 in.
(2) 3/8 in.
90
o
5.6 psi
(1) 3/8 in.
(1) 1/2 in.
RKN28520
(2) 1/2 in.
(2) 1/2 in.
90
o
5.6 psi
(1) 1/2 in.
PART NO.
SUPPLY PORT DELIVERY PORT
CONTROL
CRACK PRESSURE
RKN28085
(1) 1/2 in.
(4) 3/8 in.
(1) 3/8 in.
4.6 psi
RELAY VALVE SPRING BRAKE
PART NO.
SUPPLY PORT DELIVERY PORT CONTROL PORT CRACK PRESSURE
RKN28041
(2) 1/2 in.
(4) 1/2 in.
(2) 1/4 in.
4.6 psi
RELAY VALVE WITH DC
PART NO.
SUPPLY PORT DELIVERY PORT CONTROL PORT CRACK PRESSURE
APPLICATION
RKN28053
(2) 1/2 in.
(4) 1/2 in.
(2) 1/4 in.
4.6 psi - primary
control port
9.6 psi - secondary
control port
Replaces
973 298 057 0
RKN28055
(2) 1/2 in.
(4) 1/2 in.
(2) 1/4 in.
4.6 psi - primary
control port
9.6 psi - secondary
control port
Replaces
973 298 048 0
