HOW TO SELECT U—JOINT KITS
Meritor offers U-joints in a full range of sizes for automotive as well as On and Off-highway truck and
equipment applications
All sizes and types of Meritor U-joint kits are basically the same. They consist of the following:
• A cross
• Four (4) bearing races
• Seals
• Needle bearings
• Hardware to retain the bearings in the yoke
• Lube fitting (for most kits)
METHODS OF RETAINING U-JOINT KITS
Meritor U-joint Kits are catalogued by methods of retention within their basic style groups shown on the
following pages. Each U-joint kit section uses specific illustrations showing primary dimensions for
determining the part number.
The following table shows the basic kits styles used on passenger cars and light duty trucks regardless of
vehicle model:
VEHICLE
MANUFACTURER
MERITOR
CLEVELAND
DETROIT
SAGINAW/MECH.
AMC/JEEP OSR
-
ISR
-
CHRYSLER OSR
-
ISR
-
FORD
OSR
ISR
-
-
GMC
OSR
-
-
INJECTED NLYON/ISR
IHC
OSR
ISR
-
-
For medium and heavy-duty trucks, buses and off-highway equipment, use this catalog to identify the style
of U-joint kit that needs replacing and match the dimensions from these pages with the dimensions of the
worn kit
.
