TRANSMISSION SLIP YOKES — OUTSIDE SNAP RINGS
TRANSMISSION SLIP YOKES — INSIDE SNAP RINGS
Center to End Length of Hole
Yoke Dimension
Across Ears
Bearing Cap
Diameter
Seal Diameter
Joint Angle
Spline Length
Part Number
121N SERIES 0.998” - 20 SPLINE (Based on 22 Involute Spline) U-JOINT KIT: CP443X
6.00"
4.73"
2.69"
1.06"
1.38"
20°
CB
121N-3-686X
121N SERIES 1.005” - 22 SPLINE (Based on 24 Involute Spline) U-JOINT KIT: CP443X
4.75"
3.48"
2.69"
1.06"
1.38"
20°
CB
121N-3-1224-1X
6.00"
4.73"
2.69"
1.06"
1.38"
20°
CB
121N-3-1224X
121N SERIES 1.102” - 21 SPLINE (Involute Spline) U-JOINT KIT: CP443X
6.00"
4.73"
2.69"
1.06"
1.50"
20°
FS
121N-3-2321X
Center to End Length of Hole
Yoke Dimension
Across Ears
Bearing Cap Diameter
Seal Diameter
Spline Length
Part Number
3R SERIES 1.17” - 26 SPLINE (Based on 27 Involute Spline) U-JOINT KIT: CP3147X
5.47"
4.59"
2.56"
1.13"
1.50"
FS
R3R-3-6081X
3R SERIES 1.39” - 31 SPLINE (Based on 32 Involute Spline) U-JOINT KIT: CP3147X
7.50"
6.50"
2.56"
1.13"
1.88"
CB
R3R-3-9131X
7.50"
6.50"
2.56"
1.13"
1.88"
FS
R3R-3-9161X
8.06"
6.70"
2.56"
1.13"
1.88"
FS
R3R-3-9101X
Spline Length: CB - Counterbore in end of barrel. FS - Fully Splined
