LIGHT BARS
WAR
Customer Service: 800-562-5012 / Technical Support: 888-562-5012
152
LED
Super 44
®
Strobe w/Turn Signal
Override
Material:
• Acrylic lens
• ABS housing
• Packard connection
• 16 gauge wire
• Hard-wired
Light Source:
• 6 Light Emitting Diodes (LEDs)
• Designed at 12v, .700 amps
• 9v minimum operating voltage
• Quad flashing pattern
Kit Components:
44110Y kit:
2 - 44217Y in-phase lamps
2 - 44218Y out-phase lamps
44144Y kit:
2 - 44248Y in-phase lamps
2 - 44249Y out-phase lamps
Legal Specifications:
• Strobe meets SAE J845 Class II
selective coverage warning device
• Turn function meets SAE J1395
rear turn signal lamps
• Overvoltage protection to 600v
meets SAE J1455
4.31"
0.99"
0.69"
• Super 44® Series strobe lamp provides quad
flash pattern with solid state LED technology
• Turn signal override feature momentarily
overrides strobe function allowing lamps to
signal for turn functions
• Lateral system allows alternating flash patterns
without the need of a separate box, saving on
cost & additional installation time
• Uses Truck-Lite’s 6-Diode 4” round optics
pattern to compliment S/T/T and B/U
applications
• Fully encapsulated electronics & hard wired
design protect lamp from corrosion & damage
caused by chemicals & moisture
• New lamp design features slim profile for
mounting in limited space areas
• Using 2 in-phase lamps or 2 out-phase lamps
provides a synchronized flash, 1 in-phase lamp
& 1 out-phase lamp provides alternating flash
44110Y Yellow, kit w/connectors
44217Y Yellow, in-phase lamp w/connectors
44218Y Yellow, out-phase lamp w/connectors
44114Y Yellow, kit, blunt cut
44248Y Yellow, in-phase blunt cut
44249Y Yellow, out-phase blunt cut
1.74
5.50
4.35
1.74
• External power pack not required
• Metalized reflector version offers more
intense focused light
• Non-metalized version offers wider
viewing angle
• Dual or quad flashing patterns
• Meets recommended SAE J1318 & J845
photometric specifications
• Synchronized alternating feature
• Lamp life rated at 100,000 hours
• Resistance to shock & vibration
• Fit ’N Forget® adapter plug provides
corrosion & moisture resistance
• Integral flange option features
LED
Super 44
®
Strobe System
42 Diode Pattern
Material:
• Polycarbonate lens, housing
& flange
• PVC grommet
• 16 gauge wire
Light Source:
• Light Emitting Diodes (LEDs)
• Designed at .13.5v, .50 amp
Kit Components:
44102R/Y grommet kits:
1 - 44212R/Y metalized
reflector
1 - 40700 grommet
1 - 95220 connector
44101R/Y grommet kits:
1 - 44211R/Y non-metalized
reflector
1 - 40700 grommet
1 - 95220 connector
44104Y flange kits:
1 - 44214R/Y metalized
reflector
1 - 95220 connector
44103Y flange kits:
1 - 44213R/Y non-metalized
reflector
1 - 95220 connector
Recommended Accessories:
• Mounting: Pages 253-255
Grommet Kits w/Metalized
Reflector
44102R Red
44102Y Yellow
Grommet Kits w/Non-
Metalized Reflector
44101R Red
44101Y Yellow
LED Lamp w/Metalized
Reflector
44212R Red
44212Y Yellow
LED Lamp w/Non-
Metalized Reflector
44211R Red
44211Y Yellow
LED Lamp & Gray Flange
w/Metalized Reflector
44214R Red
44214Y Yellow
LED Lamp & Gray Flange
w/Non-Metalized Reflector
44213R Red
44213Y Yellow
Flange Kits w/Metalized
Reflector
44104Y Yellow
Flange Kits w/Non-
Metalized Reflector
44103Y Yellow
