161 / 348
TRAFFIC CONTROL
Truck-Lite Full Line Product Catalog
Customer Service: 800-562-5012 / Technical Support: 888-562-5012
159
WAR
LED
Traffic Control
Material:
• Polycarbonate lens
• Anodized aluminum housing
Light Source:
• Amps: 2.1
• Voltage: 10-16v
92869Y
92868Y
• Extremely weather resistant & high
efficient LED optics
• Control unit is micro-processor
controlled with tactile front
• Modules front load for easy
replacement of individual lightheads
• Meets J595 Class 1 and J578 Color
92868Y LED module, 1-1/2”H x 47-1/2”W x 1-1/2”D
92869Y LED module, 2-7/32”H x 47-1/2”W x 1-1/2”D
43.25
2.46
4.41
5.18
43.85
2.54
41.50
1.44
Signal-Stat
®
Auxiliary Traffic
Control Advisors
Material:
• Polycarbonate lens
• Aluminum housing
• 18 gauge wire
Replacement Parts:
• 60-20123 bulb, 20w
• 92849 control head for 1968A
• Perfect for mounting to a utility body, the rear of a light bar, or as a stand alone rear deck unit
• Lightweight aluminum housing
• Halogen model includes tilt/pedestal mounting brackets that will accommodate vertical or horizontal mounting
surfaces – no large body panel cutouts required for installation
• L.E.D. model features low profile surface mount which installs easily with just four screws Includes mounting hardware,
control head, 15’ cable & connectors
• L.E.D. model offers long life (L.E.D.s rated for 100,000 hours) and low current draw (.5 amp per lamp)
• Current draw on halogen model is 1.5 amps. per light head at 13.6 VDC
• Control head features four operating modes & eight programmable patterns with L.E.D. display of pattern in operation
9680A Eight lamp halogen traffic advisor with control head, black powder painted finish
19680A Eight lamp L.E.D. traffic advisor with control head, black powder painted finish
9680A
19680A
9680
19680
