177 / 348
Truck-Lite Full Line Product Catalog
Customer Service: 800-562-5012 / Technical Support: 888-562-5012
175
MIRRORS
MIR
Convex Mirror Head
Offset w/Heater
8-1/2” Round
Material:
• Steel housing
• Silvered glass
Recommended Accessories:
• 97823 universal mounting kit
• 97828 fender mount bracket
• 97829 tripod mound bracket
Convex Mirror Head
7-1/2” Round
Material:
• Stainless steel housing
Convex Mirror Head
8-1/2” Round
Material:
• Steel housing
• Silvered glass
Recommended Accessories:
• 97823 universal mounting kit
• 97828 fender mount bracket
• 97829 tripod mound bracket
8.50
1.75
.75
8.50
1.75
.75
97817
97814
• Mounting: 5/16” female adjustable
ball stud and bolt
• Replaces Signal-Stat 7077
• Popular school bus convex head
• Mounting: 5/16” female
adjustable ball stud and bolt
• Replaces Signal-Stat
7073/7074/7090
• 2.5 amps 12 VDC only
• 60” wire length (can use switch #102)
• Mounting: 5/16” female threaded
adjustable ball stud with 1/2” bolt
• Replaces Signal-Stat 7078/7079/7091
Full-Bubble
Wide Angle
Convex Mirror Head
8-1/2” Round
Material:
• Painted steel housing
• Acrylic mirror
• Extra wide design helps eliminate
blind spots for medium duty vehicles
• Mounts on a 5/16” adjustable,
female threaded ball stud to
prevent thread damage
• For use on many medium duty
vehicles and buses
• Replaces Signal-Stat 7046
8.406
3.250
8.50
Cross View Convex
Mirror Hear
10-1/2” Round
Material:
• Steel housing
• Acrylic lens
10.50
11.00
• Replacement mirror
head for vans, straight
trucks and panel trucks
• Directly replaces mirror
head on 97862 assemblies
• 5/16” adjustable female
ball stud and bolt included
• Increases visibility in blind spots
• Replaces Signal-Stat 7796/7797
7.50
97815 Convex mirror,
stainless steel, centered
97816 Convex mirror, black,
centered, ribbed
97817 Convex mirror, stainless steel,
w/offset mount
97803 Convex mirror, stainless steel
97804 Convex mirror, black
97814 Convex mirror, stainless steel,
w/offset mount
97614 Convex mirror stainless
steel, heated
97615 Convex mirror, black,
heated
97831 Full bubble wide angle convex mirror, black
97606 Full bubble wide angle convex mirror, stainless steel
97863 Cross view convex mirror, stainless steel
