SLACK ADJUSTERS
MERITOR PREMIUM CLEARANCE SENSING AUTOMATIC SLACK ADJUSTERS
TRANSIT APPLICATIONS
EUCLID KIT
NO.
INCLUDES
BRACKET NO.
ANGLE
STRAIGHT/
OFFSET
SPLINE SIZE
ARM
LENGTH
BUSHING
I.D.
APPLICATION
M807547 R810300
34° Straight
1-1/2”28 6”
1/2” Includes bracket and hardware.
Replaces 4W9015
M807521 R810309
34° Offset LH
1-1/2” 1-1/2”10 7”
1/2”
Single bend, 64mm. Includes bracket
and hardware. Replaces 4W8500;
3001009
M807523 R810309
34° Straight
1-1/2”10 7”
1/2”
Single bend, 64mm. Includes bracket
and hardware. Replaces 4W8645;
30010003
M807530 R810315
34° Offset LH
1-1/2” 1-1/2”10 6”
1/2”
Single bend, 64mm. Includes bracket
and hardware. Replaces 4W8600;
30010043
M807534 R810312
34° Straight
1-1/2”28 6-1/2” 1/2”
Single bend, 60mm. Includes bracket
and hardware. Replaces 4W8520;
30010068
M807531 R810315
34° Offset RH
1-1/2” 1-1/2”10 6”
1/2”
Single bend, 64mm. Includes bracket
and hardware. Replaces 4W8570;
30010044
M807539 R810316
34° Offset LH
1-1/2” 1-1/2”10 7”
1/2”
Single bend, 60mm. Includes bracket
and hardware. Replaces 4W8615;
30010020
M807540 R810316
34° Offset RH
1-1/2” 1-1/2”10 7”
1/2”
Single bend, 60mm. Includes bracket
and hardware. Replaces 4W8630;
30010021
M807542 R810328
34° Offset RH
1-1/2” 1-1/2”10 6”
1/2”
Single bend, 64mm. Includes bracket
and hardware. Replaces 4W8605;
30010026
M807546 R810328
34° Offset LH
1-1/2” 1-1/2”28 5-1/2” 1/2” Includes bracket and hardware.
Replaces 4W9010;
M807550 R810329
34° Straight
1-1/2”28 6-1/2” 1/2”
Single bend, 64mm. Includes bracket
and hardware. Replaces 4W8690;
30010053
M807553 R810331
34° Straight
1-1/2”10 5-1/2” 5/8” Includes bracket and hardware.
Replaces 4W9050
M807557 R810333
34° Offset LH
1-1/2” 1-1/2”10 6”
1/2”
Single bend, 65mm. Includes bracket
and hardware. Replaces 4W8625;
30010174
M807558 R810333
34° Offset RH
1-1/2” 1-1/2”10 6”
1/2”
Single bend, 65mm. Includes bracket
and hardware. Replaces 4W8595;
30010175
M807522 R810336
34° Offset RH
1-1/2” 1-1/2”10 7”
1/2”
Single bend, 64mm. Includes bracket
and hardware. Replaces 4W8650;
30010002
M807524 R810336
34° Straight
1-1/2”10 7”
1/2”
Single bend, 64mm. Includes bracket
and hardware. Replaces 4W8610;
30010004
M807563
120° Offset RH
5/8”
1-1/2”26 5-1/8” 1/2” Double bend, 65mm. Replaces
4W3115
M807564
120° Offset LH
5/8”
1-1/2”26 5-1/8” 1/2” Double bend, 65mm. Replaces
4W3120
