SLACK ADJUSTERS
MERITOR PREMIUM CLEARANCE SENSING AUTOMATIC SLACK ADJUSTERS
TRANSIT APPLICATIONS
EUCLID KIT
NO.
INCLUDES
BRACKET NO.
ANGLE
STRAIGHT/
OFFSET
SPLINE SIZE
ARM
LENGTH
BUSHING
I.D.
APPLICATION
M807525 R810304
23° Offset LH
1-1/2” 1-1/2”10 5-1/2” 1/2”
Single bend, 60mm. Includes bracket
and hardware. Replaces 4W8540;
30010007
M807526 R810304
23° Offset LH
1-1/2” 1-1/2”10 5-1/2” 1/2”
Single bend, 60mm. Includes bracket
and hardware. Replaces 4W8545;
30010008
M807532 R810312
23° Offset LH
5/8”
1-1/2”28 5-1/2” 1/2”
Single bend, 60mm. Includes bracket
and hardware. Replaces 4W8510;
30010066
M807533 R810312
23° Offset RH
5/8”
1-1/2”28 5-1/2” 1/2”
Single bend, 60mm. Includes bracket
and hardware. Replaces4W8515;
30010067
M807528 R810328
23° Offset LH
5/8”
1-1/2”28 5-1/2” 1/2”
Single bend, 60mm. Includes bracket
and hardware. Replaces 4W8620;
30010041
M807529 R810328
23° Offset RH
5/8”
1-1/2”28 5-1/2” 1/2”
Single bend, 60mm. Includes bracket
and hardware. Replaces 4W8635;
30010042
M807537
28° Offset RH
1-9/16” 1-1/2”26 5-1/8” 1/2” Double bend, 66mm. Replaces
4W3265
M807538
28° Offset LH
1-9/16” 1-1/2”26 5-1/8” 1/2” Double bend, 66mm. Replaces
4W3270
M807545
34° Offset RH
1-1/2” 1-1/2”10 5-1/2” 1/2” Single bend, 60mm. Replaces
4W8560; 30010035
M807541
34° Offset LH
1-1/2” 1-1/2”10 6”
1/2” Single bend, 64mm. Replaces
4W8640; 30010025
M807544
34° Offset LH
1-1/2” 1-1/2”10 6”
1/2” Replaces 4W9030
M807552
34° Straight
1-1/2”10 6”
1/2” Single bend, 64mm. Replaces
4W9040
M807554
34° Offset LH
1-1/2” 1-1/2”10 7”
1/2” Double bend, 69mm. Replaces
4W8590; 30010145
M807555
34° Offset RH
1-1/2” 1-1/2”10 7”
1/2” Double bend, 69mm. Replaces
4W8680; 30010146
