CAMSHAFTS
CAMSHAFT REPAIR KITS
E-11450HD-2 For 16-1/2” Dia. Cam Brakes
EUCLID NO.
ITEM QTY.
DESCRIPTION
APPLICATION & GENERAL INFO.
E-11449
1 1 Bronze Camshaft Bushing FOR HENDRICKSON Intraax
16-1/2” BRAKE
Half kit includes exactly half of
Kit E-11450HD for one wheel end.
2” bushing and seal O.D.
E-11451
2 2 Camshaft Seal
E-1113
3 2 Washer
E-1318AHD
4 1 Camshaft Support Bracket
E-2720
5 1 Camshaft Lock Ring
E-564
6 4 Camshaft Spacer Washer
E-656
7 1 Camshaft “D” Washer
E-719
8 2 Camshaft Spacer Washer
E-801
9 1 Lock Ring
E-11819 For 16-1/2” Dia. Cam Brakes
EUCLID NO.
ITEM QTY.
DESCRIPTION
APPLICATION & GENERAL INFO.
E-1565
1 1 Washer
FOR EATON
16-1/2” BRAKE
E-2405
2 1 Seal
E-5137
3 1 Washer
E-526
4 1 Ring
E-801
5 1 Washer
E-11897 For 16-1/2” Dia. Cam Brakes
EUCLID NO.
ITEM QTY.
DESCRIPTION
APPLICATION & GENERAL INFO.
NSS*
1 1 Outer Cam Washer
FOR HENDRICKSON Intraax
16-1/2 IN. BRAKE
Replaces Hendrickson S-26348.
Includes cam tube. Services one
wheel end.
NSS*
2 1 Cam Tube Assembly
NSS*
3 4 Capscrew
NSS*
4 4 Flanged Head Lock Nut
NSS*
5 2 Journal Washer
NSS*
6 3 Spline Inner Washer
NSS*
7 2 Cam Tube Bracket
NSS*
8 1 Snap Ring
NSS*
9 1 Snap Ring
E-11977 For 16-1/2” Dia. Cam Brakes
EUCLID NO.
ITEM QTY.
DESCRIPTION
APPLICATION & GENERAL INFO.
E-11952
1 2 Retainer Bushing
FOR HENDRICKSON Intraax
16-1/2 IN. BRAKE
Services 2 brakes. Use with
fabricated spiders. Trailer axle
cam with bolt-on bushings.
E-801
2 2 Snap Ring
E-1113
3 4 Washer
E-1319A-1
4 8 Self-Tap Screw
E-1318A
5 2 Retainer
E-6077
6 2 Outer Washer
E-9072
7 2 Washer - Flat
E-9077
8 2 Snap Ring
E-2405
9 4 Seal
*Not Sold Separately
