CAMSHAFTS
CAMSHAFT REPAIR KITS
E-2088AHD For 16-1/2” Dia. Cam Brakes
EUCLID NO.
ITEM QTY.
DESCRIPTION
APPLICATION & GENERAL INFO.
E-2380
1 2 Camshaft Outer Bushing
FOR LATE MODEL MERITOR “P”
SERIES TRAILER BRAKES
With 1-1/2” Dia. Camshafts.
Contains Lock Rings for
Camshafts with narrow or wide
grooves. Contains
E-1318AHD Heavy-Duty Support
Assembly.
E-1271
2 2 Camshaft Inner Bushing
E-1272
3 2 Camshaft Seal
E-1318AHD
4 2 Camshaft Support Bracket
E-564
5 8 Camshaft Spacer Washer
E-526
6 4 Camshaft Lock Ring
E-1416
7 2 Camshaft Seal
E-4736
8 2 Camshaft Lock Ring
E-2088AHD-2 For 16-1/2” Dia. Cam Brakes
EUCLID NO.
ITEM QTY.
DESCRIPTION
APPLICATION & GENERAL INFO.
E-2380
1 1 Camshaft Outer Bushing
FOR LATE MODEL MERITOR “P”
SERIES TRAILER BRAKES
With 1-1/2” Dia. Camshafts.
Contains Lock Rings for
Camshafts with narrow or wide
grooves. Contains
E-1318AHD Heavy-Duty Support
Assembly. Half kit includes
exactly half of Kit E-2088AHD for
one wheel end.
E-1271
2 1 Camshaft Inner Bushing
E-1272
3 1 Camshaft Seal
E-1318AHD
4 1 Camshaft Support Bracket
E-564
5 4 Camshaft Spacer Washer
E-526
6 2 Camshaft Lock Ring
E-1416
7 1 Camshaft Seal
E-4736
8 1 Camshaft Lock Ring
E-2089 For 16-1/2” Dia. Cam Brakes
EUCLID NO.
ITEM QTY.
DESCRIPTION
APPLICATION & GENERAL INFO.
E-536
1 2 Camshaft Bushing
FOR EARLY MODEL EATON
(SHULER) 5” ROUND AXLE
(Bolt-On Spiders)
E-1385
2 2 Camshaft Bushing
E-654
3 4 Camshaft Seal
E-580
4 8 Camshaft Spacer Washer
E-656
5 2 Camshaft “D” Washer
E-1569
6 2 Camshaft Lock Ring
E-526
7 2 Camshaft Lock Ring
E-2090 For 16-1/2” Dia. Cam Brakes
EUCLID NO.
ITEM QTY.
DESCRIPTION
APPLICATION & GENERAL INFO.
E-1567
1 4 Camshaft Spider Bushing FOR LATE MODEL FRUEHAUF Pro-
Par AXLES WITH
16-1/2” BRAKES
Also used on 12-1/4” Brakes
E-1577A
2 2 Camshaft Bushing
E-580
3 2 Camshaft Spacer Washer
E-1565
4 6 Camshaft Spacer Washer
E-1569
5 2 Camshaft Lock Ring
E-526
6 2 Camshaft Lock Ring
E-801
7 2 Lock Ring
