275 / 561
3-2
U.S. 888-725-9355
Canada 800-387-3889
BRAKE CHAMBERS
HALDEX CAM SPRING BRAKES AND COMPONENTS
BRAKE SERVICE CHAMBERS FOR S-CAM BRAKES
EUCLID NO. REPLACES HALDEX NO.
A
MODEL NO.
PUSH ROD THREAD SIZE
E-12S
SC12
4”
Type 12
1/2”-20
E-16S
SC16
4-19/32”
Type 16
1/2”-20
E-20S
SC20
7”
Type 20
5/8”-18
E-24S-L
SC24L
7-1/2”
Type 24
5/8”-18
E-24S
SC24
7-1/2”
Type 24
5/8”-18
E-30S
SC30
8-13/64”
Type 30
5/8”-18
E-36S
SC36
9-5/16”
Type 36
5/8”-18
BRAKE SERVICE CHAMBER DIAPHRAGMS - Nylon Fabric Reinforced Rubber
EUCLID NO.
FOR SERVICE CHAMBER
A DIAMETER
E-12734
T-36
8-1/2”
E-12772
T-20L
6-9/16”
E-12773
T-30L
7-7/8”
CLEVIS ASSEMBLIES AND CLEVIS PINS
EUCLID NO.
REPLACES
HALDEX NO.
DESCRIPTION
CLEVIS
THREAD SIZE
CLEVIS PIN
DIA.
E-12756
CF1
Clevis Assy. - Forged
1/2”-20
1/2”
E-12757
CF2
Clevis Assy. - Forged
5/8”-18
1/2”
E-12761
CS2
Clevis Assy. - Stamped
5/8”-18
1/2”
PRESSURE HOUSING
EUCLID NO.
REPLACES
HALDEX NO.
TYPE
STROKE
GENERAL INFORMATION
E-12777
PH30
T-30
2.50” (64mm)
3/8”-18 NPTF air inlet
