WEDGE BRAKES
PARTS FOR BENDIX WEDGE BRAKE
EUCLID NO.
REPLACES
SLOT WIDTH
APPLICATION AINFORMATION
E-2282
Dayton/Batco 07571
Dayton/Batco 08130600
Trailmobile 382282
Dana/Spicer 437037
Bendix 445342
Meritor KIT970
Leland L1301
Meritor R670022
1/4”
Non-Servo. Adjusting Screw. Use
with 15” x 3 and 3-1/2” shoes
E-2281
Dayton/Batco 07570
Bendix 318657
Bendix 445343
Leland L1300
Meritor R670021
5/16”
Twin Plex. Adjusting Screw. Use
with 15” x 5, 6 and 7” shoes
EUCLID NO.
DESCRIPTION
REPLACES
O.D.
LENGTH
APPLICATION
E-1217
Adjusting Nut Cap
Dayton/Batco 07586
Bendix 316355
Haldex 65401
Leland L972
Meritor R670004
Meritor R670029
E-2162
Adjusting Spring
Dayton/Batco 07601
Bendix 249941
Bendix 316370
Leland L1012
Meritor R670019
3/4” 1-1/2”
EUCLID NO.
DESCRIPTION
REPLACES
E-1215
Adjusting Nut Spring
Dayton/Batco 07587
Bendix 316356
Haldex 65409
Leland L1011
Meritor R670002
EUCLID NO.
DESCRIPTION
REPLACES
E-1216
Adjusting Nut
Dayton/Batco 07585
Bendix 316354
Haldex 65400
Leland L971
Meritor R670003
EUCLID “HDG” WEDGE BRAKE LUBRICANT
E-2015
APPLICATION
HDG is recommended for all Wedge Brakes. Apply HDG generously to the Plungers and Rollers of the
Wedge Assembly and to the inside of the Seal Assembly also. Each can is 6-1/2 oz.
HDG is formulated to:
* Withstand High Temperatures
* Be Waterproof
* Be Corrosion Resistant
* Provide Long Life
* Resist Extreme Pressure
* Be Smooth In Texture
* Have A Thin Film Capacity
