SERVICE TOOLS
AIR BRAKE SERVICE TOOLS
HEAVY-DUTY BRAKE DRUM GAUGE KIT
EUCLID NO.
DESCRIPTION
GENERAL INFORMATION
E-9136
Heavy-Duty Brake Drum
Gauge Kit
To quickly and easily measure scored, worn or
heat-checked brake drums. Includes: Heavy-Duty
Brake Drum Gauge, Gauge Calibration Tool, Euclid
red hard plastic shell with padded interior to
protect the Brake Drum Gauge.
Measures any brake drum from 12” to 18” diameter
in 1/4” increments. Both end tips of gauge are
made with hardened steel balls inserted at contact
points for accuracy and service. Easy-to-adjust
slide bar shows exact drum diameter to be
checked.
E-9139
Brake Lining/Block
Thickness Gauge
Simplifies checking standard and oversized
brake lining. Readings can be recorded in either
percentages or linear measure.
SLACK ADJUSTER PULLERS
EUCLID NO.
SLACK TYPE
GENERAL INFORMATION
E-9319
Manual
Eases the job of removing frozen slack adjusters. Available for Manual
and Automatic Slack Adjusters. Slack Pullers have only one moving part
and require only a wrench to use them. There are only four simple steps
to follow to use the tools:
1. Remove the grease fittings from the slack adjuster.
2. Slide the puller onto the slack adjuster body.
3. Turn the bolt on the puller. The bolt is self-aligning for quick
positioning.
4. Catch the slack adjuster as it comes off the camshaft.
E-9320
Automatic
CLEVIS PIN PRESS
EUCLID NO.
GENERAL INFORMATION
E-3379
10,000 lb. capacity press shears cotter pin and pushes out
ROLL PIN PUNCH TOOL
EUCLID NO.
GENERAL INFORMATION
E-2098
Designed to remove E-626 Roll Pins. The smaller end will pilot in the roll pin
and prevent punch from slipping.
BUSHING REMOVAL AND INSTALLATION TOOL
EUCLID NO.
GENERAL INFORMATION
E-1362
Use to remove or install 1-1/4” I.D. press-in anchor pin bushings.
E-1250
Use to remove or install 1-1/2” I.D. press-in type camshaft bushings.
E-2739
Use to remove or install 1-5/8” I.D. press-in type camshaft bushings.
