Euclid Brakes-Air Catalog

7-12

U.S. 888-725-9355

Canada 800-387-3889

SERVICE TOOLS

FRONT END SERVICE TOOLS

EUCLID NO.

DESCRIPTION

APPLICATION

E-2654

Ball Joint and Anchor

Pin Press

A heavy-duty press that easily removes rusted and

corroded brake shoe anchor pins without damage to

the brake shoe spider. Removes pins up to 1-1/4”

diameter. Use with E-6064 set to remove or install

Ball Joints. Also used to remove Brake Shoe Anchor

Pins and U-Joints.

E-6064

Ball Joint Service Set

Includes: 3” x 3-3/4” I.D. Receiver Tube; 2-1/2”

O.D. x 2-1/4” I.D. Receiver Tube; 2” O.D. x 1-3/4”

I.D. Receiver Tube; Installation Adapter; Removal

Adapter. Requires use of an

E-2654 Ball Joint Press.

E-6065

Ball Joint Spanner

Wrench

For removal and installation of Ball Joint Adjusting

Sleeves on 1/2, 3/4 and 1-Ton Dana open yoke front

axles used on Ford, GMC, Navistar and Jeep 4WD

vehicles. Allows torquing with 1” socket for proper

upper Ball Joint preload.

E-6066

Ball Joint Separator

Ball Joint Separator is designed solely to remove Ball

Joints from spindle support arms without damaging

other components.

E-6067

Multi-Purpose

Separator

This tool can be used to remove camber adjustment

sleeves on Ford 4 x 2 and 4 x 4 light trucks where the

camber is adjustable. It can also be used as a Pitman

Arm wedge for Light-Duty Trucks as well as a Tie

Rod Separator for Medium and Heavy-Duty Trucks.

E-6068

Pitman Arm Puller

Pitman Arm Pullers are designed to handle the

toughest Pitman Arm pulling job. Pullers are

adjustable and have special forged jaws shaped to fit

the job. “Pullers have two clamp bolts that lock jaws

on the Pitman Arm for pulling, assuring positive grip

and leaving hands free for the pulling job.” Light-

Duty Trucks - 1 Ton only

E-6069
