431 / 561
7-14
U.S. 888-725-9355
Canada 800-387-3889
SERVICE TOOLS
MISCELLANEOUS SERVICE TOOLS
WHEEL BEARING ENDPLAY GAUGE
EUCLID NO.
APPLICATION
E-9793
Quick and Accurate:
1. Remove magnet keepers and attach to face of
trailer hub with indicator contacting end of the
spindle.
2. Zero dial by rotating the dial face.
3. Rock the hub and drum to determine bearing
endplay.
4. Adjust bearing endplay and recheck.
U-JOINT PULLER
EUCLID NO.
APPLICATION
E-6039
Works on most Dana Spicer and Meritor U-joints. Designed for use with a 1/2” air
impact wrench. Can be used at different angles and in tight places. Holes in the
puller legs store bolts.
Bolts included are: (2) 5/16”-24 x 1-1/2”; (2) 3/8”-24 x 1-1/2”; (2) 7/16 in-20 x
1-1/2”; (2) M8 x 1.25mm x 35mm
UNIVERSAL BEARING CUP INSTALLER
EUCLID NO.
APPLICATION
E-6040
Designed for installing wheel bearing cups of tractor and trailer wheels from 11,000
to 50,000 lbs. capacity. Adjust from 3-5/8” to 6-1/2” dia. bearing cup.
To Use:
1. Adjust and lock the jaws to the cup I.D.
2. Slip on new cup and put it in place in the wheel.
DUAL WHEEL PULLER
EUCLID NO.
CAPACITY CASTER INFO. FLOOR SPACE LIFT TRAVEL TILT ADJUSTMENT
APPLICATION
E-9433
1,500 lbs.
3-1/2”
Swivel
45” x 41” 4-3/4”
4 Degrees
Allows one person to easily
remove, transport and
replace dual wheel and tire
assemblies.
6 ft. chain and hydraulic
jacking mechanism with
handle included. Replaces
OTC No. 1770A
FLYWHEEL HANDLING ATTACHMENT
EUCLID NO.
APPLICATION
E-9435
Attaches to E-9434 Clutch Handler for removal of flywheels
(including pot type). Replaces OTC No. 218174.
