BENDIX HYDRAULIC DISC BRAKE
BENDIXHYDRAULICDISCBRAKE
PART NO.
DESCRIPTION
NOTES
E-4105
HARDWARE KIT
Services One Wheel
E-6119
SEAL KIT
Second Design Boot Seal is made
with a metal insert and is driven into
the caliper housing. Second Design
Boot Seal has only 2 folds in the
rubber. First and Second Design
Pistons and Seals are not
interchangeable.
E-4101
BOLT
E-6118
PISTON
Second Design Piston is phenolic
with a metal face designed to reduce
wear caused by abrasion on the Disc
Pad. First and Second Design Pistons
and Seals are not interchangeable.
Diameter — 2.60”
Piston Type — Phenolic/Steel
E-D380-S
STOPMATE DISC
FMSI Outer Pad No. — D380-O
FMSI Inner Pad No. — D380-I
Inner Pad Backing Lining Length —
6.828
Inner Pad Backing Plate Length —
8.078
Outer Pad Backing Lining Length —
10.00
Outer Pad Backing Plate Length —
10.0625
