BOSCH HYDRAULIC DISC BRAKE
BOSCHHYDRAULICDISCBRAKE
PART NO.
DESCRIPTION
NOTES
E-11754
HARDWARE KIT
Services one wheel. Not actual piston
shown.
Guide Pin1 — BX4153231
Diameter — 66mm
Guide Pin Boot 1 — BX4153232
Slippers 1 — BX4153343
Slippers — 2
Guide Pin Bolt — 2
Guide Pin — 2
Guide Pin Boot — 2
E-11755
SLIPPER
Not Actual Piston Shown
Diameter — 66mm
Slippers — 2
E-11752
SEAL KIT
Boots 1 — BX4153266
Guide Pin Bolt — BX4153235
Seals — 2
Boots — 2
E-11751
PISTON
Not Actual Piston Shown
Diameter — 66mm
E-D786A-S STOPMATE DISC
FMSI 7654D786 Thin Set
FMSI Outer and Inner Pad Number —
D786
Pad Length — 9.61
Outer Pad Backing Plate Height —
3.230”
Outer Pad Backing Plate Length —
9.6094”
