1-19
BOSCH HYDRAULIC DISC BRAKE
BOSCHHYDRAULICDISCBRAKE
PART NO.
DESCRIPTION
NOTES
E-11754
HARDWARE KIT
Services one wheel. Not actual piston
shown.
Guide Pin1 — BX4153231
Diameter — 66mm
Guide Pin Boot 1 — BX4153232
Slippers 1 — BX4153343
Slippers — 2
Guide Pin Bolt — 2
Guide Pin — 2
Guide Pin Boot — 2
E-11755
SLIPPER
Not Actual Piston Shown
Diameter — 66mm
Slippers — 2
E-11758
SEAL KIT
E-11757
PISTON
Actual piston not shown.
Diameter — 73mm
E-D786-S
STOPMATE DISC
FMSI No. — 7655-D786
FMSI Disc Pad No. — D786
Outer Pad Backing Plate Height —
3.23
Outer Pad Backing Plate Length —
9.6094
