20 / 257
1T15L-4
5681
13.6
Granning 5492
Granning 5385 (no
stud)
W01-358-8922
1T15L-4
5361
14.4
Hendrickson 58983-2
(Blue Bird)
W01-358-8942
BRACKET
WC1-358-3904
1T15L-4
12.9
Reyco 19624-01
REPLACEMENT
PISTON COMES
WITHOUT STUDS
W01-358-8951
1T15L-4
3159
15.7
Kenworth K-303-5
Replacement piston
comes without studs
W01-358-9415
1T15L-4
3604
14.6
Waggoner’s Truck
W01-358-9438
1T - Reversible Sleeve
BELLOW NO.
ASSEMBLY
ORDER NO.
CROSS SECTION VIEW BEAD PLATE
TOP VIEW
PISTON
BOTTOM VIEW
ASSEMBLY
WEIGHT
(lbs.)
REPLACES
No Alignment Specified-Center Stud Mounting is Standard
Bolt or Stud 1/2-13
Combination Stud/Air Inlet Stud Outside Thread is 3/4-16
Threaded Hole 3/8-16 Blind Nut on Bead Plates 1/2-13 Pistons
Air Inlet 1/4 N.P.T.
Studs Inside Thread (Air Inlet) is 1/4 N.P.T. Exceptions WIll Be Noted on Part View as
Hardware Key
19
1T Style Springs
