1T15LC-2.5
11.8
Navistar 1672401C1
(GY 1R12-204)
W01-358-9566
1T15LC-4.5
3159
14.1
Navistar 2027913C1
(GY 1R12-325)
W01-358-9567
1T15LC-4.5
3159
14.5
Navistar 1675495C1
(GY 1R12-205)
W01-358-9568
1T15LC-12
5699
16.2
Hendrickson Trailer
S23614
W01-358-9619
1T15LP-1.5
3285
14.6
Hendrickson Truck
65790-2
W01-358-8597
1T - Reversible Sleeve
BELLOW NO.
ASSEMBLY
ORDER NO.
CROSS SECTION VIEW BEAD PLATE
TOP VIEW
PISTON
BOTTOM VIEW
ASSEMBLY
WEIGHT
(lbs.)
REPLACES
No Alignment Specified-Center Stud Mounting is Standard
Bolt or Stud 1/2-13
Combination Stud/Air Inlet Stud Outside Thread is 3/4-16
Threaded Hole 3/8-16 Blind Nut on Bead Plates 1/2-13 Pistons
Air Inlet 1/4 N.P.T.
Studs Inside Thread (Air Inlet) is 1/4 N.P.T. Exceptions WIll Be Noted on Part View as
Hardware Key
23
1T Style Springs
