Firestone Catalog

1T17CL-5

5699

17.5

Hendrickson Trailer

S22046 (HK230)

Approximate

availability 1-98 -

-replaces

W01-358-8756

W01-358-8710

1T17CL-9.5

5699

18.9

Hendrickson Trailer

S20127 [HT-250U

9-006] [HT-250UY

9Y-006] replaces

1T15VLT-10.5

1T15V-11

W01-358-9262

W01-358-9580

REPLACES

1T15VLT-10.5

1T17CL-9.5

5699

19.0

Hendrickson Trailer

S20414 [HT-250U

(9-006)] [HT-250U-Y

(9Y-006)] Replaces

1T15VLT-10.5

1T15V-11

W01-358-9581

REPLACES

1T15VLT-10.5

1T19J-1

3147

OBSOLETE

NO LONGER AVAILABLE

17.0

Ridewell

1003588055C

W01-358-8055

OBSOLETE

1T19L-3

5361

19.0

Granning 7593

W01-358-8760

BELLOW NO.

ASSEMBLY

ORDER NO.

CROSS SECTION VIEW BEAD PLATE

TOP VIEW

PISTON

BOTTOM VIEW

ASSEMBLY

WEIGHT

(lbs.)

REPLACES

No Alignment Specified-Center Stud Mounting is Standard

Bolt or Stud 1/2-13

Combination Stud/Air Inlet Stud Outside Thread is 3/4-16

Threaded Hole 3/8-16 Blind Nut on Bead Plates 1/2-13 Pistons

Air Inlet 1/4 N.P.T.

Studs Inside Thread (Air Inlet) is 1/4 N.P.T. Exceptions WIll Be Noted on Part View as

Hardware Key
