1T17B-11
3159
18.0
Holland (Neway)
90557168
(AR250-12,16,17)
W01-358-8749
1T17BB-2
5699
13.2
Meritor 202796 (GY
1R13-130)
W01-358-8729
1T17BP-17
38.9
Hendrickson Trailer
S22697
W01-358-8724
SERVICE ASSEMBLY
761
1T17C-3
5681
14.7
Tuthill Granning
705951-01
W01-358-8636
1T17C-3
5648
15.0
Tuthill Granning
700999-01
W01-358-8733
1T - Reversible Sleeve
BELLOW NO.
ASSEMBLY
ORDER NO.
CROSS SECTION VIEW BEAD PLATE
TOP VIEW
PISTON
BOTTOM VIEW
ASSEMBLY
WEIGHT
(lbs.)
REPLACES
No Alignment Specified-Center Stud Mounting is Standard
Bolt or Stud 1/2-13
Combination Stud/Air Inlet Stud Outside Thread is 3/4-16
Threaded Hole 3/8-16 Blind Nut on Bead Plates 1/2-13 Pistons
Air Inlet 1/4 N.P.T.
Studs Inside Thread (Air Inlet) is 1/4 N.P.T. Exceptions WIll Be Noted on Part View as
Hardware Key
79
1T Style Springs
